Pelco KSC-3000U Controller

Brand: Pelco
Part Number: KSC-3000U
Write a Review
  • Pelco KSC-3000U Controller
  • Pelco KSC-3000U Controller
Free shipping over $300 Free Shipping
Technical Support Technical Support
1 Year Warranty 1 Year Warranty


Pelco KSC-3000U Controller

The KSC-3000U Series is a USB keyboard controller for use with Pelco’s analog cameras (Pelco D and P Protocol) including the Spectra Mini (SD5 Series), Spectra IV, and Esprit SE.

The KSC-3000U Series is capable of half and full duplex mode with two RS-485 ports.

The KSC-3000U Series can be used as a mouse, keyboard, or joystick for a PC or network video recorder without external driver installation. Alphanumeric characters’ input is supported through the numeric keypad in Keyboard Mode. Mouse scroll and sensitivity setting is supported in Mouse Mode.

All hotkeys for the PC applications can be supported with the controller’s shortcut keys in Hotkey Mode. Create and modify shortcut keys using the system controller.

All buttons on the KSC-3000U Series can be used as the joystick buttons and are programmable except for ESC (when exiting from HID mode) and USB HID (when changing from three different HID modes).

The KSC-3000U Series features a built-in 3-Axis proportional joystick, LCD, rubber buttons, and Jog Shuttle for ease of operation.

Key Features:

  • All-In-One mouse, keyboard, joystick
  • Two RS-485 ports
  • Shortcut keys
  • Provides a variety of add-ons
  • More than 16 built-in protocols
  • Built-in Jog shuttle, joystick for user convenience


Additional Information

NDAA Compliance:
NDAA Compliant
1-year Manufacturer Warranty
