Raytec RM300-PLT-AI-30 Raymax 300 Platinum IR Illuminator - 30-90 degree AI, 850nm

Brand:
Part Number: RM300-PLT-AI-30
Write a Review
  • Raytec RM300-PLT-AI-30 Raymax 300 Platinum IR Illuminator - 30-90 degree AI, 850nm
  • Raytec RM300-PLT-AI-30 Raymax 300 Platinum IR Illuminator - 30-90 degree AI, 850nm
$1,975.00
OR
Free shipping over $300 Free Shipping
Technical Support Technical Support
5 Year Warranty 5 Year Warranty
  • Field of View (Horizontal) : 30°Field of View
  • Color : Black
  • Environmental : Outdoor

Description

Raytec RM300-PLT-AI-30 Raymax 300 Platinum IR Illuminator - 30-90 degree AI, 850nm

The RM300 PLATINUM is the latest generation of the RAYMAX series, designed specifically for long distance or wide angle applications. RM300-PLT provides World class performance, long life and zero maintenance. RM300-PLT incorporates the very latest surface mount LED's to deliver excellent night-time pictures with improved optical output and outstanding reliability.

Ultimate Adaptive Illumination™ provides the flexibility to alter the angle of illumination on site to suit specific security needs and to match the camera's field of view. RAYMAX illuminators are also purpose designed to provide even output illumination.

Each unit is fitted with Active LED Life Control to carefully control LED output, delivering consistent illumination power and a projected working life of 10 years.

RAYMAX illuminators are supplied with bracket and power supply. Control features on the power supply include adjustable power output, photocell and telemetry control. RM300-PLT is suitable for all low light installations up to 1,000 metres. (3,280ft)

POWERFUL

  • Distances up to 1,000m (3,280ft)
  • PLATINUM LED technology
  • Ultra high power - Low running costs

FLEXIBLE

  • Ultimate Adaptive Illumination™
  • Various Angles (5° - 180°+)
  • Fully Controllable Power Supply

RELIABLE

  • 10 year life
  • Active LED Life Control
  • Vandal Resistant

CONTROLLED

  • Zero Light Pollution
  • Even Output Illumination
  • Semi-Covert (850nm)

Key features:

  • 30-90 degree
  • AI, 850nm + PSU
  • Narrow Angle: 250m (820ft)
  • Wide Angle: 150m (493ft)
Available Models and Specs:
  • 2x RM300-PLT-AI-05 2x Raymax 300 Platinum can deliver Narrow 1000m(3280ft) - Wide 500m(1,640ft)
  • RM300-PLT-AI-05 RAYMAX 300 Platinum, 10-20° AI, 850nm + PSU Narrow 700m(2,297ft)- Wide 350m(722ft)
  • RM300-PLT-AI-30 RAYMAX 300 Platinum, 30-60° AI, 850nm + PSU Narrow 250m(820ft)- Wide 150m(493ft)
  • RM300-PLT-AI-50 RAYMAX 300 Platinum, 50-100° AI, 850nm + PSU Narrow 175m(459ft) - Wide 125m(410ft)
  • RM300-PLT-AI-120 RAYMAX 300 Platinum, 120-180° AI, 850nm + PSU Narrow 100m(328ft) - Wide 63m(205ft)

This product is also associated with:

Raytec

View AllClose

Additional Information

Accessory Type:
Infrared Illuminators
Color:
Black
Environmental:
Outdoor
Field of View (Horizontal):
30
Power Consumption:
120 Watts
Warranty:
5-year Manufacturer Warranty
Wavelength (nm):
850
