Raytec VAR2-i4-1-C Medium Range Infrared Illuminator
VARIO2 is the next generation of Infra-Red and White-Light illuminators from Raytec. Using the latest PLATINUM Elite SMT LEDs, VARIO2 allows cameras to generate longer illumination distances using less power. VARIO2 features an interchangeable lens system with Hot-spot Reduction Technology to deliver highly even illumination where it is most needed. With the optional hand-held remote control, VARIO2 also makes installation and commissioning quicker, easier and safer. The VARIO2 i4-1 Infra-Red series delivers maximum distances up to 144m (472ft).
Key Features:
- Low Voltage Infra-Red Illuminators
- PLATINUM Elite SMT LED Technology
- VARIO Interchangeable Lens System
- Angles 10-120 degrees from 1 product
- Hot-spot Reduction Technology (HRT)
- Advanced Security Settings
- 940nm
- IP66
- 13 watt max. consumption
- 9 IR LEDs
- 2.1lbs
- 5-Year Manufacturer Warranty
- Power adjust from 20-100%
- In-built photocell for automatic on/off operation
- Photocell following output
- Photocell sensitivity adjust
- LED status indicator provides status on performance of the unit
- LED status indicator on/off
- Disable programming mode
Downloads
Datasheet
Raytec-VAR2-i4-1-C-Specsheet-A1.pdf
Datasheet
Raytec-VAR2-i4-1-C-Installation-A1.pdf
Popular Search
Additional Information
|
Accessory Type:
|
Infrared Illuminators
|
|
Color:
|
Black
|
|
Environmental:
|
Outdoor
|
|
Input Voltage:
|
24VAC
|
|
Max Power Consumption:
|
13 Watts
|
|
Night Vision Range (ft):
|
472
|
|
Warranty:
|
5-year Manufacturer Warranty
|
|
Wavelength (nm):
|
940
|
