Samsung Hanwha TEC-F04 4 Channel Ethernet over Coax Extender With Pass-Through PoE

Samsung Hanwha TEC-F04 4 Channel Ethernet over Coax Extender With Pass-Through PoE

The Ethernet over copper TEC-F / TEC-U Series supports up to sixteen channels of 10/100Mbps Ethernet with Pass-through PoE over twisted pair cable (CAT-5, UTP), or over coaxial cable. The single channel units may be powered by a PoE switch or the included power supply. Four and sixteen channel units operate from local power. These units provide the ultimate flexibility for extending a powered device (PD) over long distance copper. DIP switches are provided for user-selection of local or remote, 10/100Mbps, and 1-pair or 4-pair (UTP) settings

Key Features:

• Transmits individual Ethernet data channels with Pass-through PoE over standard Coaxial cable
• Extends Ethernet up to 5,000 feet (1,524 m) at 10 Mbps or 2,000 feet (610m) at 100 Mbps over Coaxial cable
• Extended temperature operation from -40ºC to +75ºC
• Extended Pass-through PoE meets the IEEE 802.3af standard for Power over Ethernet
• Full 10/100 Mbps Bandwidth
• Symmetric Bandwidth provides consistent upload and download with virtually zero packet loss over the total usable distance
• Perfect to retrofit existing analog CCTV installations to Ethernet-based systems
• Designed for CCTV systems for casinos, airports, school campuses, & more...
