Samsung Hanwha TMC-FSTM1POEM-A Hardened 100 Mbps Media Converter with PoE+
The TMC-FSTM1POEM-A is a hardened 100 Mbps Ethernet-to-fiber media converter designed for long-distance transmission and reliable PoE+ power delivery. This model supports multimode fiber via an ST connector and provides up to 30W PoE+ output, making it ideal for roadside, industrial, and remote device installations. Featuring IEEE 802.3af/at compliance, automatic MDI/MDI-X, and robust environmental protection, the TMC-FSTM1POEM-A ensures dependable operation in harsh conditions. The SKU TMC-FSTM1POEM-A supports transmission distances up to 3 km and maintains full functionality in extreme temperatures, delivering a highly durable and efficient networking solution.
Key Features:
- Hardened 100 Mbps media converter; supports 10/100BASE-T/TX to 100BASE-FX conversion over multimode fiber
- PoE+ output up to 30W; fully compliant with IEEE 802.3af/at for powering remote devices
- Extended temperature tolerance; operates from -40°C to +75°C for harsh outdoor environments
- Multimode ST fiber interface; supports distances up to 3 km for long-range applications
- Electrical and optical port protection; includes transient surge protection and meets NEMA TS-1/TS-2 standards
Downloads
Popular Search
Additional Information
|
Accessory Type:
|
Transceiver
|
|
Color:
|
Gray
|
|
Converter Type:
|
Fiber Optic Media Converter Unit
|
|
Dimensions:
|
155 x 135 x 28 mm (6.1 x 5.3 x 1.1 in)
|
|
Fiber Ports:
|
1x 100Mbps ST
|
|
LED Indicator:
|
|
|
Manufacturer Website:
|
https://hanwhavisionamerica.com/
|
|
Max Power Consumption:
|
33 Watts
|
|
Network Interface:
|
1x RJ-45 10/100 Mbps
|
|
Number of PoE Ports:
|
1 PoE Port
|
|
PoE Standards:
|
IEEE 802.3at
IEEE 802.3af
|
|
Power Budget:
|
30 Watt
|
|
Power Supply:
|
8 to 24 VDC
22 to 27 VAC
|
|
Power for each port:
|
30W
|
|
Warranty:
|
3-year Manufacturer Warranty
|
