4K Support:
|
4K Supported
|
|
Alarm Input:
|
4 Channel
|
|
Alarm Output:
|
2 Channel
|
|
Audio Output:
|
1x 3.5mm
|
|
Capacity for each disk:
|
up to 6TB
|
|
Certifications:
|
UL Listed
|
|
Channel Capacity:
|
16 Channels
|
|
Color:
|
Black
|
|
Compatible Integration (API):
|
ONVIF
Wisenet open platform
|
|
Compliance:
|
NDAA Compliant
|
|
Connection Type:
|
Wired
|
|
Dimensions:
|
440 x 89.8 x 426.3 mm (17.32 x 3.54 x 16.78 in)
|
|
Environmental:
|
Indoor
|
|
Hard Drive Ports:
|
4 SATA Ports
|
|
LED Indicator:
|
|
|
Manufacturer Website:
|
https://hanwhavisionamerica.com/
|
|
Material:
|
Metal
|
|
Max Power Consumption:
|
320 Watts
|
|
Max. Incoming Bandwidth:
|
150Mbps
|
|
Max. Recording Resolution:
|
8MP (4K)
|
|
Max. Storage Capacity:
|
24 TB
|
|
Mounting:
|
Rack Mount
|
|
Network Interface:
|
2x RJ-45 1000 Mbps Port
16x RJ-45 10/100 Mbps
|
|
Number of PoE Ports:
|
16 PoE Ports
|
|
Operating Humidity:
|
20% to 85% RH (non-condensing)
|
|
Operating System:
|
Linux Ubuntu 18.04 LTS
|
|
Operating Temperature:
|
0 °C to 40 °C (32 °F to 104 °F)
|
|
PoE Standards:
|
IEEE 802.3af
IEEE 802.3at
|
|
Power Budget:
|
200 Watt
|
|
Power Supply:
|
100 to 240 V AC
|
|
Power for each port:
|
30W
|
|
Pre-Installed Storage:
|
4 TB
|
|
Product Series:
|
Samsung Hanwha Wisenet WAVE VMS Series
|
|
Rack Unit (U):
|
2U
|
|
Recorder Technology:
|
Network Video Recorder (NVR)
|
|
Special Recorder Features:
|
Wisenet WAVE Video Management System
|
|
USB Interface:
|
2x USB 2.0
1x USB 3.0
|
|
Video Output:
|
1x HDMI
1x VGA
|
|
Warranty:
|
3-year Manufacturer Warranty
|
