Samsung Hanwha WRT-P-3101MW-1TB 16 Channel, 45Mbps WAVE Recording Server, 1TB HDD

Brand: Hanwha Vision
Part Number: WRT-P-3101MW-1TB
Write a Review
Replacement: There is no direct replacement. Ask a representative.
Check other similar products:
NDAA Compliant Cameras
Hanwha Vision Video Recorders
Hanwha Vision NDAA Compliant
Discontinued
  • Samsung Hanwha WRT-P-3101MW-1TB 16 Channel, 45Mbps WAVE Recording Server, 1TB HDD - 2
  • Samsung Hanwha WRT-P-3101MW-1TB 16 Channel, 45Mbps WAVE Recording Server, 1TB HDD - 3
  • Samsung Hanwha WRT-P-3101MW-1TB 16 Channel, 45Mbps WAVE Recording Server, 1TB HDD - 4
  • Samsung Hanwha WRT-P-3101MW-1TB 16 Channel, 45Mbps WAVE Recording Server, 1TB HDD - 5
  • Samsung Hanwha WRT-P-3101MW-1TB 16 Channel, 45Mbps WAVE Recording Server, 1TB HDD - 6
  • Hanwha Vision WRT-P-3101MW-1TB
Free shipping over $300 Free Shipping
Technical Support Technical Support
5 Year Warranty 5 Year Warranty
  • Pre-Installed Storage : 1 TB
  • Video Output : 1x HDMI 1x VGA 1x DisplayPort
  • Hard Drive Ports : 1 SATA Port
  • Max. Storage Capacity : 2 TB Storage Capacity
  • Color : Black
  • Material : Metal Plastic
  • Environmental : Indoor

Related Products

Description

Samsung Hanwha WRT-P-3101MW1TB 16 Channel, 45Mbps WAVE Recording Server, 1TB HDD

The WRT-P-3101MW server is a micro form factor Wisenet WAVE server designed to record up to 16 cameras. The server has a dedicated solid state drive for video storage and a separate M.2 SSD for the Windows 10 IoT Enterprise LTSC operating system to provide fast boot and load times.

This micro server offers unrivaled deployment flexibility, allowing for its small chassis to be deployed in any small business environment. An optional VESA mount allows the server to be inconspicuously mounted behind a monitor.

Each server is pre-configured with Wisenet WAVE VMS and preloaded with 4 Professional licenses to ensure quick and easy deployment with minimum setup time.

Key Features:

  • Micro form factor Wisenet WAVE Network Video Recorder
  • Includes 4 Professional licenses
  • Wisenet WAVE pre-installed
  • 45 Mbps recording B/W
  • (1) 2.5" HDD
  • (12th Gen) Intel Core i3, 8GB RAM
  • 256 GB SSD OS Drive
  • Windows 10 IoT Enterprise
  • (1) HDMI, (1) DisplayPort output
  • 1 GbE NIC
  • Keyboard and mouse included

Downloads

Quick Start Guide WAVE-Server-QSG

Popular Search

NDAA Compliant Cameras
Hanwha Vision Video Recorders
Hanwha Vision NDAA Compliant

Additional Information

4K Support:
4K Supported
Audio Capability:
Two-Way Audio
Audio Input:
1x 3.5mm
Audio Output:
1x 3.5mm
Capacity for each disk:
up to 2TB
Certifications:
UL Listed cUL CB FCC
Channel Capacity:
16 Channels
Color:
Black
Compliance:
NDAA Compliant
Dimensions:
36 x 178 x 182 mm (1.4 x 7.0 x 7.2 in)
Environmental:
Indoor
Hard Drive Ports:
1 SATA Port
Included Licenses:
4 Wisenet WAVE Professional License
Manufacturer Website:
https://hanwhavisionamerica.com/
Material:
Metal Plastic
Max Power Consumption:
65 Watts
Max. Incoming Bandwidth:
45Mbps
Max. Storage Capacity:
2 TB
Mounting:
VESA Standalone
Network Interface:
1x 1 GbE
Operating Humidity:
20% to 80% RH (non-condensing)
Operating System:
Windows 10 IoT Enterprise
Operating Temperature:
10 °C to 35 °C (50 °F to 95 °F)
Power Supply:
100 to 240 V AC
Pre-Installed Storage:
1 TB
Processor (CPU):
Intel Core i3
Product Series:
Samsung Hanwha Wisenet WAVE Series
RAM:
8GB
RAM Type:
DDR4
Recorder Technology:
Video Server
SSD Capacity:
256GB
Special Recorder Features:
Next Business Day Onsite Support Keep Your Hard Drive Warranty
Storage Temperature:
-40 °C to 65 °C (-40 °F to 149 °F)
USB Interface:
2x USB 2.0 4x USB 3.2 Gen 1
Video Output:
1x HDMI 1x VGA 1x DisplayPort
Warranty:
5-year Manufacturer Warranty
