Description
Samsung Hanwha XRN-2010A 32 Channel 4K Network Video Recorder without HDD
The XRN-2010A is a 4K network video recorder that supports up to 32 channels, H.265/H.264/MJPEG, ARB & failover (N+1), 8 fixed internal SATA HDDs (with a maximum internal storage capacity of 48TB), e-SATA/iSCSI storage, WiseStream compression technology, dual monitor video out, supports camera resolution up to 12 MP recording/display and fisheye dewarping on web and CMS. Includes QR code for easy mobile app access.
Key Features:
- Up to 32CH, Max. 12MP Camera supported
- 256Mbps network camera recording
- 4K video out on HDMI monitor support
- Dual monitor video out support
- H.265, H.264, MJPEG compression support
- WiseStream support
- Max. 8 internal HDDs (48TB), e-SATA / iSCSI storage support
- ARB & Failover (N+1) support
- P2P service (QR code connect) support
- 1x HDMI, 1x VGA dual monitor, Expand/Clone modes
- RJ-45, Gigabit ethernet x 2
- 1 e-SATA
- 2U
Downloads
Quick Start Guide
Hanwha-Techwin-(Samsung)-XRN-2010A-Quick-Start-Guide-A1
Popular Search
Additional Information
|
4K Support:
|
4K Supported
|
|
Capacity for each disk:
|
up to 6TB
|
|
Channel Capacity:
|
32 Channels
|
|
Color:
|
Black
|
|
Compression:
|
H.265
H.264
MJPEG
|
|
Hard Drive Ports:
|
8 SATA Ports
|
|
LED Indicator:
|
|
|
Languages:
|
English
|
|
Manufacturer Website:
|
https://hanwhavisionamerica.com/
|
|
Max. Incoming Bandwidth:
|
256Mbps
|
|
Max. Recording Resolution:
|
12MP (4K)
|
|
Max. Storage Capacity:
|
48 TB
|
|
Pre-Installed Storage:
|
No HDD included
|
|
Product Series:
|
Samsung Hanwha Wisenet X Series
|
|
Rack Unit (U):
|
2U
|
|
Recorder Technology:
|
Network Video Recorder (NVR)
|
|
Video Output:
|
1x HDMI
1x VGA
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
e-SATA:
|
e-SATA
|
