Samsung SPE-101 Network Video Encoder - H.264

Part Number: SPE-101
Write a Review
Replacement: There is no direct replacement. Ask a representative.
Check the other awesome products:
  • Samsung SPE-101 Network Video Encoder - H.264
  • 3 Years Limited Manufacturer Warranty
Technical Support Technical Support
3 Year Warranty 3 Year Warranty
  • Compression : H.264, MJPEG, MPEG4,
  • Color : White

Customers Also Viewed


Samsung SPE-101 Network Video Encoder

Samsung SPE-101 Network Video Encoder assists in digital data transmission over the network. This device compresses audio and video signals from a single analog camera into digital data. The encoder supports H.264, MPEG-4, and MJPEG formats for transmission and ensures that the quality is not compromised. The encoder allows you to record live footage in real time at full frame rate and controls compatible PTZ cameras via an RS-422 or RS-485 port.

Key features of Samsung SPE-101

  • Maximum Resolution 704 x 480 (4CIF)
  • Power over Ethernet Capability
  • Ethernet Port / ONVIF Compliant
  • 1.69 x 1.41 x 3.76"
  • 0.251 Lbs. (115 g)
  • Vpp / 75 Ω composite CVBS
  • Vpp / 75 Ω composite Video In CVBS
  • Built-in De-interlacing filter
  • Event Trigger Motion detection, video loss
  • Remote Control Interfaces RS-422/485
  • RS-485 Protocol Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, GE, Bosch, Sungjin
  • Ethernet RJ-45 (10/100BASE-T)
  • H.264, MPEG-4, MJPEG Video compression format
  • Resolution 704 x 480, 640 x 480, 352 x 240, 320 x 240
  • Frame Rate 30 fps (maximum)
  • Compression level, target bitrate level control
  • H.264, MPEG-4: CBR or VBR, MJPEG: VBR Bitrate control method
  • Multiple streaming (Up to 10 profiles)
  • IPv4, IPv6

The terminal blocks for this device will be included in the box, and those will be the screw down terminals.

This product is also associated with:

Samsung Hanwha

Additional Information

Accessory Type:
Video Encoder
Channel Capacity:
1 Channel
3-year Manufacturer Warranty
