Description
Samsung SRD-1680D 16CH HD-SDI Hybrid Digital Video Recorder
The SRD-1680D from Hanwha Techwin is a HD/SD hybrid DVR that provides 16CH 700TVL and 8CH Full HD 1080p real-time recording. It offers maximum Full HD 1920 x 1080 resolution for NTSC and PAL, and the max frame rate is 480fps (NTSC and 400 for PAL). The SRD-1680D offers various smart video analysis functions including smart searching and tampering. User can extend the storage by installing up to 4 HDDs and using DVD-RW and USB for back up. Network throughput is up to 64Mbps.
Key features:
- 16CH 700TV lines / 8CH Full HD 1080p Real-time Recording
- Max. 4 Internal HDDs
- Full HD, VGA/HDMI Video Output
- HDD Removable (Easy Install)
- Smart Searching, Tampering Support
- Up to 64Mbps Network Bandwidth
Downloads
Datasheet
srd-1680d_datasheet-A1.pdf
Additional Information
|
Channel Capacity:
|
16 Channels
|
|
Compression:
|
H.264
|
|
Manufacturer Website:
|
https://hanwhavisionamerica.com/
|
|
Max. Incoming Bandwidth:
|
64Mbps
|
|
Max. Recording Resolution:
|
2MP
|
|
Pre-Installed Storage:
|
No HDD included
|
|
Recorder Technology:
|
Digital Video Recorder (DVR)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
