Speco SX800 800W Solar Powered Camera Enclosure System with MPPT Charge Controller

Speco SX800 800W Solar Powered Camera Enclosure System with MPPT Charge Controller

The Speco SX800 is an 800W solar power system designed for off-grid security and camera installations at remote sites. It combines a solar panel array with a weatherproof aluminum enclosure and an advanced MPPT charge controller, representing the highest-capacity array in Speco's SX product family. The system supplies continuous power for multi-camera sites, high-draw PTZ cameras, cellular routers, and PoE switches, including in regions with lower average solar radiation.

Power management uses an MPPT (Maximum Power Point Tracking) charge controller to maximize solar-to-battery energy conversion, with charging profiles optimized for both LiFePO4 lithium iron phosphate and standard sealed lead-acid batteries. The internal battery bay accommodates up to two 100Ah batteries, which are sold separately; battery chemistry significantly affects total installed weight, with SLA units adding roughly 66 lbs each against approximately 24 lbs for LiFePO4.

The aluminum enclosure measures 21.5" H x 16" W x 14.5" D and weighs approximately 28 lbs empty. The array consists of four 200W high-efficiency monocrystalline panels measuring 59" x 27" each, rated to withstand 100 MPH wind loads and mounted on 3" to 6" Schedule 40 poles. Operating range spans -40°F to 140°F. Cameras and batteries are not included; the factory-integrated PoE switch and 4G LTE cellular router are available on the SXC and SXP series rather than this model.

Key Features:

• 800W solar array with four 200W monocrystalline panels; the highest generation capacity in Speco's SX product family.
• MPPT charge controller; maximizes solar-to-battery conversion efficiency across varying light and battery conditions.
• Dual battery chemistry support; optimized charging profiles for both LiFePO4 and sealed lead-acid batteries.
• Weatherproof aluminum enclosure, 21.5" x 16" x 14.5"; protects the charge controller and wiring from weather and tampering.
• Internal bay for two 100Ah batteries (sold separately); supports configurable autonomy for the connected load.
• Sized for high-draw loads; supports multi-camera sites, PTZ cameras, cellular routers, and PoE switches.
• 100 MPH wind rating on 3" to 6" Schedule 40 poles; withstands severe weather at exposed installations.
• Operating range of -40°F to 140°F; suits year-round deployment across most North American climates.
