Speco SXC800 800W Solar Powered Camera Enclosure System with PoE Switch and 4G LTE Router

Speco SXC800 800W Solar Powered Camera Enclosure System with PoE Switch and 4G LTE Router

The Speco SXC800 is the most complete configuration in Speco's solar infrastructure line, delivering both power and cellular connectivity in a single housing for sites that have neither grid electricity nor wired or fiber network access. It is built for construction sites, agricultural land, mining operations, and remote facilities where cameras need to be connected and monitored remotely through cloud or mobile applications without any existing infrastructure.

The 800W monocrystalline array is managed by an integrated MPPT (Maximum Power Point Tracking) charge controller, with charge profiles supporting both high-cycle-life LiFePO4 lithium iron phosphate batteries and conventional SLA or gel types. The enclosure accepts up to two 100Ah batteries, sold separately.

Networking hardware ships factory-installed. The integrated 4G LTE cellular router works with SIM cards from major carriers including AT&T, T-Mobile, and Verizon as well as international equivalents, enabling live remote viewing, cloud recording, and remote management. The internal PoE switch supplies both power and data to connected IP cameras over a single Cat5 or Cat6 run. The NEMA-rated, powder-coated, lockable aluminum enclosure measures 21.5" H x 16" W x 14.5" D and weighs approximately 28 lbs empty. The array uses four 200W panels measuring 59" x 27" each at roughly 75 lbs per mount assembly, rated to 100 MPH wind on 3" to 6" Schedule 40 rigid metal poles, operating from -40°F to 140°F. The system meets NDAA Section 889 requirements. Batteries, IP cameras, SIM card, and pole straps are not included.

Key Features:

• 800W monocrystalline solar array; delivers the highest energy harvest in the Speco solar line for demanding remote sites.
• Factory-integrated 4G LTE cellular router; provides remote viewing, cloud recording, and management with no wired network present.
• Integrated PoE switch; carries power and data to IP cameras over a single Cat5 or Cat6 cable.
• MPPT charge controller; maximizes solar-to-battery conversion across varying light and battery conditions.
• Dual battery chemistry support; charge profiles for both LiFePO4 and traditional SLA or gel batteries.
• NEMA-rated lockable aluminum enclosure, 21.5" x 16" x 14.5"; protects router, switch, and controller from weather and tampering.
• NDAA Section 889 compliant; eligible for federal and government-funded procurement.
• Internal capacity for two 100Ah batteries (not included); supports configurable autonomy for the connected load.
• 100 MPH wind rating on 3" to 6" Schedule 40 poles; withstands severe weather at exposed installations.
• Operating range of -40°F to 140°F; industrial-grade tolerance for year-round deployment.
