Speco SXP800 800W Solar Powered Camera Enclosure System with 4 Port PoE Switch

Speco SXP800 800W Solar Powered Camera Enclosure System with 4 Port PoE Switch

The Speco SXP800 combines the highest-capacity solar array in the series with an integrated PoE switch, forming a complete off-grid power and network distribution solution. It is designed for sites that already have LAN connectivity available through fiber, a point-to-point wireless bridge, or external modem infrastructure, and therefore need PoE distribution to multiple IP cameras from a single point without an onboard cellular modem.

The 800W array provides substantial generation headroom, maintaining uninterrupted power at northern latitudes, through overcast conditions, in shaded locations, or wherever extended battery life is a priority. An integrated MPPT (Maximum Power Point Tracking) charge controller manages conversion, with charge profiles supporting both high-cycle-life LiFePO4 lithium iron phosphate batteries and standard SLA or gel types. The enclosure holds up to two 100Ah batteries, which are not included.

The four-port PoE switch mounted inside the enclosure supplies both power and data to connected IP cameras and network devices. Unlike the SXC series, the SXP800 does not include a SIM-based 4G LTE router. The NEMA-rated powder-coated aluminum enclosure measures 21.5" H x 16" W x 14.5" D and weighs approximately 28 lbs empty. The array consists of four 200W high-efficiency monocrystalline panels measuring 59" x 27" each, weighing approximately 75 lbs per mount assembly, rated to 100 MPH wind and mounted on 3" to 6" Schedule 40 rigid metal poles. Operating range spans -40°F to 140°F. Batteries, cameras, and pole straps are not included.

Key Features:

• 800W solar array with four 200W monocrystalline panels; the highest generation capacity in the SXP series.
• Integrated four-port PoE switch; delivers power and data to multiple IP cameras from a single enclosure.
• MPPT charge controller; maximizes solar-to-battery conversion across varying light and battery conditions.
• Dual battery chemistry support; charge profiles for both LiFePO4 and standard SLA or gel batteries.
• Strong low-irradiance performance; sustains operation at northern latitudes, in shade, and through overcast periods.
• NEMA-rated powder-coated aluminum enclosure, 21.5" x 16" x 14.5"; protects switch, controller, and wiring from weather and tampering.
• Internal capacity for two 100Ah batteries (not included); supports configurable autonomy for the connected load.
• 100 MPH wind rating on 3" to 6" Schedule 40 poles; withstands severe weather at exposed installations.
• Operating range of -40°F to 140°F; suits year-round deployment across most North American climates.
• Universal mounting hardware included; supports standard pole installations.
