Vivotek CU9183-H 5MP Indoor 1.22mm Pinhole Fisheye Lens, Cylinder Shape

Vivotek CU9183-H 5MP Indoor 1.22mm Pinhole Fisheye Lens, Cylinder Shape

Please note: this product is a camera unit (sensor module) only, not a complete camera system. It does not operate on its own and must be connected to a Vivotek VC9101 video core, which is sold separately.

The Vivotek CU9183-H is an indoor fisheye camera unit from the Vivotek V (Versatile) Series, built for installations where the camera itself needs to disappear. The cylinder-shaped housing measures 0.94 x 1.46 in (24 x 37 mm) and weighs 28 g, allowing it to be recessed into ceilings, walls, cabinetry or fixtures at ATMs, bank branches, retail counters and offices. The unit connects to a VC9101 video core over a 5-meter USB Micro-B to RJ11 cable and draws less than 1.25 W, so no separate power supply is required at the sensor location.

A 1/2.7" progressive scan CMOS sensor captures a square 1920x1920 image through a fixed 1.22 mm fisheye lens with an F2.0 fixed iris, giving a full 180.0° horizontal, vertical and diagonal field of view. A single ceiling-mounted unit therefore covers an entire room with no blind corners. WDR Pro delivers 120 dB of dynamic range for scenes that mix shaded interiors with bright doorways and windows, and a minimum color illumination of 0.035 lux keeps images usable in dim lobbies and after-hours lighting. Shutter speeds range from 1/5 to 1/32,000 sec., and 3DNR noise reduction maintains a 56.3 dB signal-to-noise ratio.

The unit streams 30 fps at 1920x1920 using H.265, H.264 or MJPEG compression to balance image quality against bandwidth and storage. Both client-side and local dewarping are supported, including single fisheye, panoramic, dual panoramic and multi-region views for ceiling or wall installations. Measured to the EN 62676-4 DORI standard, the CU9183-H detects at 79.7 ft, observes at 31.5 ft, recognizes at 15.7 ft and identifies at 7.9 ft. It operates from -10°C to 50°C (14°F to 122°F) at up to 90% relative humidity, carries CE, FCC, RCM, VCCI, UL, CB and BSMI approvals, and is backed by a 60-month manufacturer warranty.

Key Features:

• Camera unit only, requires a separately sold VC9101 video core; lets you place just the sensor in tight or sensitive locations while the processing hardware sits elsewhere.
• 180.0° horizontal, vertical and diagonal field of view; one ceiling-mounted unit covers a whole room with no blind corners.
• 1920x1920 square image on a 1/2.7" progressive scan CMOS sensor; keeps detail across the full circular frame rather than only the center.
• Fixed 1.22 mm fisheye lens at F2.0; the wide aperture gathers more light for the deep coverage angle.
• WDR Pro with 120 dB dynamic range; keeps shaded interiors and bright entrances readable in the same frame.
• 0.035 lux minimum color illumination; continues producing color images in dim lobbies and low after-hours lighting.
• 30 fps at 1920x1920 with H.265, H.264 and MJPEG; H.265 cuts bandwidth and recording storage compared with H.264.
• Client and local dewarping with fisheye, panoramic and multi-region modes; operators view flat, usable images without extra software.
• 0.94 x 1.46 in (24 x 37 mm) cylinder body weighing 28 g; fits into ceilings, walls and fixtures where a standard camera cannot be concealed.
• 5-meter USB Micro-B to RJ11 cable, under 1.25 W consumption; powered entirely by the VC9101 video core, with no separate supply at the sensor.
• 60-month manufacturer warranty; long coverage for permanently installed, hard-to-reach sensor units.
