Vivotek SAA04 Panel Antenna

Brand: Vivotek
Part Number: SAA04
Write a Review
$192.03
Technical Support Technical Support
  • Color : White

Description

Vivotek SAA04 Panel Antenna

Key Features Of Vivotek SAA04

  • Frequency range 4900MHz - 5875MHz
  • Gain 17~18 dBi
  • Frequency range 4900 MHz - 5875 MHz
  • Gain 17~18 dBi
  • VSWR 2.0: 1 Max.
  • Polarization Linear, Vertical
  • HPBW / horizontal 17.5~23
  • HPBW / vertical 16~19
  • Sidelobe level Co-pol. -11.5 dB (max.), Cross-pol. -18 dB (max.)
  • Front-to-back ratio -21 dB (max.)
  • Isolation N/A
  • Power handling 5 W (cw)
  • Impedance 50 Ohms
  • Cable N/A
  • Connector N female
  • Lightning protection DC ground
  • Survival wind speed 216 km/hr
  • Temperature - 40°C to +80°C
  • Humidity 95% @ 55゚C
  • Radome color Gray-white
  • Radome material ABS, UV Resistant
  • Weight 825 g
  • Dimensions 200 x 218 x 50 mm
  • Waterproof IP-X5
  • Mount kit Pole Mount

Downloads

Datasheet SAA04-A1.pdf

Compatible products

Additional Information

Accessory Type:
Wireless Antenna
Color:
White
Frequency:
5.8 GHz
Gain:
18 dBi
Wind Survivability (mph):
134
