Description
ACTi A24 5MP H.265 Outdoor Box IP Security Camera with 3.6~10mm Varifocal Lens, Built-in Microphone
5MP, Box, Day / Night, Extreme WDR, Superior Low Light Sensitivity, Built-in Analytics.
Key features:
- Product Type : Box
- Maximum Resolution : 5MP
- Application Environment : Indoor/Outdoor
- Day / Night : Yes
- Low Light Sensitivity : Superior
- Lens : Vari-focal, f3.6-10mm / F1.5-2.8, P-Iris, Auto back focus
- Maximum Frame Rate vs. Resolution : 30fps at 2592 x 1944
- Wide Dynamic Range : Extreme WDR (100 dB)
- Local Storage : MicroSDHC, MicroSDXC
- Built-in Analytics : Yes
- 2D + 3D DNR
- 2-way, Built-in Microphone, Mic-in, Line-in, Line-out
Replacement of:
E22VA
Downloads
Datasheet
ACTi-A24-Datasheet-A1
Document
ACTi-A24-Dimensions-A1
Quick Start Guide
ACTi-A24-Quick-Start-Guide-A1
Firmware
ACTi-A24-Firmware-A1
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Aperture:
|
F1.5
F2.8
|
|
Audio Capability:
|
Two-Way Audio
|
|
Audio Compression:
|
G.711
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Audio Support:
|
Built-in Microphone
|
|
Camera Style:
|
Box
|
|
Certifications:
|
CE
FCC
EAC
|
|
Compatible Integration (API):
|
ONVIF Profile S
ONVIF Profile G
ONVIF Profile T
ONVIF Profile Q
|
|
Compression:
|
H.264
H.265
MJPEG
|
|
Dimensions:
|
62 x 58 x 141.1 mm (2.44 x 2.28 x 5.56 in)
|
|
Environmental:
|
Indoor
Outdoor
|
|
Field of View (Horizontal):
|
89.1
38.2
|
|
Iris:
|
P-iris
|
|
Lens Size:
|
3.6~10mm
|
|
Lens Type:
|
Varifocal (Manual Zoom) Lens
|
|
Max Power Consumption:
|
9 Watts
|
|
Max. FPS and Resolution:
|
30fps at 2592 x 1944
|
|
Minimum Illumination (B/W):
|
0.05 Lux at F1.5 AGC on
|
|
Minimum Illumination (Color):
|
0.1 Lux at F1.5
|
|
Mounting:
|
Wall Mount
Ceiling Mount
Corner Mount
Pole Mount
|
|
Network Interface:
|
1x RJ-45 10M/100M Base-TX Ethernet
|
|
Noise Reduction:
|
2D DNR
3D DNR
|
|
Power Supply:
|
12 VDC
PoE (IEEE 802.3af)
|
|
Product Series:
|
ACTi A-Series
|
|
Reset Button:
|
|
|
Resolution:
|
5MP (3K)
|
|
S/N Ratio:
|
56 dB
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/1.8"
|
|
Sensor Type:
|
CMOS
|
|
Serial Interface:
|
1x RS485
|
|
Shutter Speed:
|
1/5-1/64000s
|
|
Technology:
|
Network (IP)
|
|
Video Output:
|
1x CVBS
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Web Browser:
|
Internet Explorer 11
|
|
Wide Dynamic Range (WDR):
|
WDR 100dB
WDR 122dB
|
