Description
ACTi B76A 12MP 4K Night Vision Outdoor Fisheye IP Security Camera, Superior Low Light, Extreme WDR 130db
12MP, Outdoor Hemispheric Dome, Day / Night, Extreme WDR, Superior Low Light Sensitivity, Built-in Analytics.
Key features:
- Product Type : Hemispheric Dome
- Maximum Resolution : 12MP
- Application Environment : Outdoor
- Day / Night : Yes
- Low Light Sensitivity : Superior
- IR LED : Adaptive IR LED x 18 (850 nm)
- Focal Length : Fixed focal, f1.65mm
- Maximum Frame Rate vs. Resolution : 30 fps at 2048 x 2048, 18 fps at 4000 x 3000
- Wide Dynamic Range : Extreme WDR (130 dB)
- Local Storage : MicroSDHC, MicroSDXC
- Built-in Analytics : Yes
- Weatherproof IP68, NEMA4X
- Vandal Proof IK10
- 2-way, Built-in Microphone, Mic-in, Line-in, Line-out
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
Additional Features:
|
180-degree Panoramic View
Mobile App Support (IOS, Android)
|
Analytics:
|
Motion Detection
|
Aperture:
|
F2.8
|
Audio Capability:
|
Two-Way Audio
|
Audio Compression:
|
PCM
G.711
|
Audio Input:
|
1x Channel
|
Audio Output:
|
1x Channel
|
Audio Support:
|
Built-in Microphone
|
Built-in Features:
|
Built-in Analytics
|
Camera Style:
|
Dome
|
Certifications:
|
CE
FCC
UL Listed
EAC
CB
|
Color:
|
White
|
Compatible Integration (API):
|
ONVIF
ONVIF Profile S
ONVIF Profile G
ONVIF Profile T
ONVIF Profile Q
|
Compliance:
|
NDAA Compliant
|
Compression:
|
MJPEG
H.264
|
Connection Type:
|
Wired
|
Dimensions:
|
152.00 x 71.00 mm (6.0 x 2.8 in)
|
Durability:
|
Vandal Proof
Weatherproof
|
Environmental:
|
Outdoor
|
Field of View (Horizontal):
|
198.5
|
IR LED Quantity:
|
18
|
Image Enhancements:
|
Ultra Low Light
|
Iris:
|
Fixed Iris
|
Lens Mount:
|
Board Mounted
|
Lens Size:
|
1.65mm
|
Lens Type:
|
Fixed Lens
|
Max Power Consumption:
|
12.95 Watts
|
Max. FPS and Resolution:
|
18fps at 4000 x 3000
|
Max. Storage Capacity:
|
256 GB
|
Minimum Illumination (Color):
|
0.003 Lux
|
Night Vision Range (ft):
|
65
|
Night Vision Type:
|
Night Vision (IR)
|
Noise Reduction:
|
3D DNR
2D DNR
|
Power Supply:
|
PoE (IEEE 802.3af)
12 VDC
|
Product Series:
|
ACTi B-Series
|
Protection Code:
|
NEMA 4X
IP68
IK10
|
Resolution:
|
12MP (4K)
|
SD Card Support:
|
SD Card Supported
|
Sensor Size:
|
1/1.7"
|
Sensor Type:
|
CMOS
|
Shutter Speed:
|
1/5-1/16000s
|
Technology:
|
Network (IP)
|
Warranty:
|
3-year Manufacturer Warranty
|
Wavelength (nm):
|
850
|
Wide Dynamic Range (WDR):
|
WDR 130dB
|
