Aiphone KB-DAR-M Single-Gang Surface Mountable Color Video Door Station - Motion Detector Interface

Aiphone KB-DAR Color Video Door Station

Ensure safety and protection at all times with Aiphone KB-DAR Color Video Door Station. The color tilt CCD camera takes care of surveillance while the speaker and mic tend to the communication needs. The unit easily mounts to a 1 gang box, and the sturdy ABS plastic safeguards it against elements of the weather. An illuminated call button and white illumination LED enables ease of use in low-light conditions too.

• 24V DC power source
• Aiphone #871802 wire
• 330'(22AWG) 650'(18AWG) Master to door distance
• 165'(22AWG) 330'(18AWG) Master to farthest sub
• 165'(22AWG) 330'(18AWG) Master to IER-2
• Door to master wiring: 2-cond., mid cap, solid, non-shielded
• Master to subs wiring: 2 x 2-cond., mid cap, solid, non-shielded
• 12V AC, 400mA contact rating for door release
• Recommended use of RY-24L for larger contact rating
• 4" direct-view TFT color LCD video monitor
• 525 Scanning lines
• Night viewing Up to 1' from camera, with white LED projected
• Approx. 2' horizontal, 3'8"-7'9" vertical at 4'3" high and at 20" Image View Area
