AXIS 2N IP Force 2.0 5MP Outdoor IP Video Intercom with 1 Button and Keypad - 03362-001
The AXIS 2N IP Force 2.0 with integrated keypad delivers advanced visitor access control through both visual verification and secure PIN entry. This professional-grade video intercom combines a high-resolution 5MP camera with an integrated mechanical keypad, providing multiple authentication methods for enhanced security in demanding outdoor environments.
Engineered for maximum durability, this model features IP69 and IK10 protection ratings with aluminum construction, ensuring reliable performance in extreme weather conditions. The 5MP camera with 133° viewing angle provides exceptional visitor identification, while the integrated keypad allows for secure PIN-based access control. Advanced WDR technology and infrared illumination ensure clear images in all lighting conditions.
Powered by the Axis ARTPEC-8 processor, the system offers enhanced cybersecurity features including secure boot and signed firmware. The OSDP interface enables integration with card readers, while SIP 2.0 protocol support provides seamless VoIP communication. With PoE+ power delivery and professional audio capabilities, this intercom delivers enterprise-grade access control functionality.
Key Features:
- 5MP camera with 133° horizontal viewing angle and infrared illumination; ensures clear visitor identification day and night
- Integrated mechanical keypad for secure PIN-based access control; provides flexible authentication options
- IP69 and IK10 protection rating with aluminum construction; delivers maximum durability in harsh environments
- PoE+ IEEE 802.3at power support with 30W consumption; simplifies installation with single cable solution
- H.264, H.265, and MJPEG video compression; provides flexible streaming for various network conditions
- 10W amplifier with 94dB sound pressure level; ensures clear two-way communication
- Operating temperature range -30°F to +131°F; maintains reliable performance in extreme climates
- SIP 2.0 protocol with full duplex audio; enables professional VoIP integration
Downloads
Additional Information
|
Compression:
|
H.264
H.265
MJPEG
|
|
Dimensions:
|
4.29x8.54x3.27in
|
|
Field of View (Horizontal):
|
133
|
|
Field of View (Vertical):
|
112
|
|
Lens Size:
|
1.935mm
|
|
Material:
|
Aluminum
|
|
Max Power Consumption:
|
30 Watts
|
|
Minimum Illumination (Color):
|
0.1 lux
|
|
Power Supply:
|
PoE+
12VDC
|
|
Protection Code:
|
IP69
IK10
|
|
Resolution:
|
5MP
|
|
Storage Temperature:
|
-40 °C to 70 °C (-40 °F to 158 °F)
|
|
Wide Dynamic Range (WDR):
|
|
