Description
AXIS F2115-R 2MP Varifocal Sensor 2nd Generation Discreet Varifocal Sensor - 02639-001
AXIS F2115-R offers 1080p at 60 fps or 720p at 180 fps with AXIS F9111, a 107° - 56° horizontal field of view, and good low-light performance in color. It uses cables (up to 30 m/ 98 ft) from Axis with SMA-FAKRA connectors to withstand vibrations and ensure a ruggedized installation. Based on a divided network camera concept, it offers discreet installation and only a small sensor visible externally. Reliable under rough conditions, this ruggedized indoor varifocal sensor unit can withstand temperatures as low as -40 °C and as high as 70 °C intermittently (-40 °F to 158 °F).
Key Features:
- Only compatible with 2nd generation main units and cables
- Up to 60 fps at 1080p and up to 180 fps at 720p
- 107°-56° horizontal field of view
- 3.2 – 5.7 mm focal length
- Rugged sensor unit
Flexible and discreet
AXIS F2115-R offers discreet installation with only the small sensor visible externally. Based on a divided network camera concept, this varifocal sensor connects to the main unit using a ruggedized SMA-FAKRA connector. Cable type and length (up to 30 m/ 98 ft) are chosen based on your specific needs. Furthermore, there’s a variety of accessories available for mounting options and for flexible installation.
Multi-purpose
Ideal for indoor installation, in ATMs, vending machines, buses, and emergency vehicles, this varifocal sensor uses cables from Axis with SMA-FAKRA connectors to withstand vibrations and ensure a ruggedized installation. It can be installed practically anywhere- in tight spaces, behind glass, metal, or even plastic sheeting.
High-quality video usability
This varifocal sensor delivers high-quality video even in challenging and low light conditions. With a 107°-56° horizontal field of view, it’s perfect when you need to monitor a specific area of interest with great details for identification purposes. It supports HDTV 1080p at 60 fps or 720p at 30 fps on 4-channels. It also supports 720p at 180 fps with AXIS F9111 Main Unit. Forensic WDR provides clarity when there’s both dark and light areas in the scene.
Downloads
Popular Search
Compatible products
Additional Information
Accessory Type:
|
Camera Lens
|
Alternative SKUs:
|
F2115-R
|
Aperture:
|
F2.2
F3.1
|
Color:
|
Black
|
Compliance:
|
NDAA Compliant
|
Connector Type:
|
SMA
|
Diameter:
|
1.2
|
Dimensions:
|
29.8 x 50 mm (1.2 x 1.9 in)
|
Environmental:
|
Indoor
|
Field of View (Horizontal):
|
107.4
37
|
Iris:
|
Fixed Iris
|
Lens Mount:
|
M12
|
Lens Size:
|
3.2~5.7mm
|
Lens Type:
|
Varifocal (Manual Zoom) Lens
|
Material:
|
Aluminum
|
Max Power Consumption:
|
1.7 Watts
|
Minimum Illumination (Color):
|
0.1 Lux
|
Product Series:
|
AXIS F Series
|
Protection Code:
|
IP50
|
Sensor Size:
|
1/2.8"
|
Sensor Type:
|
CMOS
|
Shutter Speed:
|
1-1/27000s
|
Storage Humidity:
|
5% to 95% RH (non-condensing)
|
Storage Temperature:
|
-40 °C to 65 °C (-40 °F to 149 °F)
|
Warranty:
|
5-year Manufacturer Warranty
|
