AXIS Q7411 Single-Channel Video Encoder 0518-004

AXIS Q7411 Single-Channel Video Encoder 0518-004

AXIS Q7411 is a powerful, full-featured video encoder solution offering 60/50 (NTSC/PAL) frames per second. The support for 60/50 fps provides smooth video in high motion scenes. This also enables the user to more closely follow details and changes in the monitored area, which is of major importance in forensic work.

Full Featured Single Channel Solution AXIS Q7411 is a powerful, full-featured video encoder solution offering 60/50 (NTSC/PAL) frames per second. The support for 60/50 fps provides smooth video in high motion scenes. This also enables the user to more closely follow details and changes in the monitored area, which is of major importance in forensic work.

Coax PTZ Installation AXIS Q7411 allows PTZ control over the coaxial cable, resulting in significant installation savings. In addition, the video encoder provides standard support for PTZ cameras using the serial ports.

Reduces Bandwith and Storage Needs AXIS Q7411 offers the highly efficient H.264 video compression format both in Base and Main profile, with significant savings in bandwidth and storage. Motion JPEG is also supported for increased flexibility.

Intelligent Video Capabilities AXIS Q7411 offers intelligent capabilities such as motion detection, active tampering alarm and audio detection. Other features include two-way audio and microSD/microSDHC memory.

Key Features:

• H.264 and MJPEG Video Compression
• D1 720 x 480 Resolution at up to 60 fps
• 1 Channel; Supports Multiple Streams
• RS-485/422 Port for PTZ Camera Control
• PTZ Camera Control over Coaxial
• Video Motion Detection; Tampering Alarm
• Two-Way Audio Communication
• RJ-45 Ethernet Port for Networking
• microSD Card Slot & NAS Support
• 802.3af PoE; ONVIF Compliant
