Bosch Autodome 500 VG4-522-CTE Indoor 18x PTZ IP Security Camera

Bosch Autodome 500 VG4-522-CTE Indoor 18x PTZ IP Security Camera

Bosch Autodome 500 VG4-522-CTE is among Boschrsquo;s elite line of security cameras. Bosch security cameras boast industry leading quality and performance. Bosch security cameras include exceptional features making them the perfect solution for any video surveillance system. Below are the key features for Bosch VG4-522-CTE.

Bosch Autodome 500 VG4-522-CTE Main Features:

• •& 1/4" Exview HAD CCD imager
• •& 18x zoom (4.1-73.8 mm) lens
• •& Features 36x optical and full 12x digital zoom
• •& Provides high-quality imagery at a resolution up to 470TVL
• •& WDR function - corrects extreme lighting environments marked by high-contrast and harsh backlit scenes
• •& Autoscaling automatically sets up the camera in a default position to view the object at the correct size
• •& AutoPivot feature automatically rotates and flips the camera to ensure optimal control
• •& Day&night ICR (infrared cut filter removal) function - switches between color and B&W as per changes in ambient lighting, ensuring accurate color reproduction in daylight and enhanced B&W images at night
• •& SensUp control feature - enhances the sensitivity by automatically reducing the shutter speed to 1 second
• •& 360° per second pan/tilt speeds and supports 99 pre-position and 2 styles of guard tours - preset and record/playback
• •& Preset tour can support up to 99 pre-positions with a configurable dwell time between pre-positions
• •& Customize the order and frequency of each preset
• •& Supports 2 recording tours with up to 15 minutes recording duration
• •& Supports menu languages such as English, French, German, Spanish, Portuguese, Italian, Dutch, and Polish
• •& Advanced DSP - provides smooth tracking of images, enabling real-time video processing
• •& AutoTrack II virtual masking technology ignores extraneous background motion, making the camera ideal for both indoor and outdoor applications
• •& Video motion detection - triggers an alarm when motion is detected in a designated portion of the video display
• •& Supports up to 10 individual regions of interest
• •& Virtual masking to ignore areas of unwanted motion
• •& Image stabilization is a technique used to reduce blurring of images where the camera is subject to high frequency vibrations
• •& Camera uses rules-based logic to manage alarms
• •& Inputs and outputs with pre-defined and user-specified keyboard commands can be combined for performing advanced dome functions
• •& Handles 7 alarm inputs including 2 analog inputs that are programmed for EOLR for real-time security applications
• •& Supports 4 outputs wherein 1 relay is rated at 2A, and 3 additional open collectors for driving external devices
• •& Privacy masking is used to mask specific portions of a scene for security reasons
• •& Up to 8 masks can be displayed on the same scene
• •& Each masked area can be programmed with 3, 4, or 5 corners to hide more complex shapes
• •& Optional hybrid/IP configuration allows the camera to simultaneously stream IP video via LAN or WAN and CVBS video via coaxial cabling
• •& Tri-streaming feature - provides independent streams simultaneously
• •& Allows to stream high-quality images for live viewing and recording at a reduced frame rate
• •& Innovative CTFID (Configuration Tool for Imaging Devices) for remotely changing the camera's settings as well as update firmware
• •& Built-in diagnostics ensure easy servicing and minimize downtime
• •& Use the OSD to quickly check the critical parameters such as internal temperature and input voltage level and verify if the dome is functioning within acceptable operating limits
• •& Ethernet communication for standard video and data transmission methods such as TCP/IP
• •& IP54-rated in-ceiling enclosure
• •& Optional XT (Extended Temperature) kit allows the camera to operate in temperatures down to -76°F (-60°C)
• •& Includes a rugged polycarbonate tinted bubble for enhanced image clarity
• •& NTSC
