Bosch DVR-650-08A050 8ch DVR Digital Video Recorder (500GB)

Brand:
Part Number: DVR-650-08A050
Write a Review
Discontinued
  • Bosch DVR-650-08A050 8ch DVR Digital Video Recorder (500GB)
  • Bosch DVR-650-08A050 8ch DVR Digital Video Recorder (500GB)
$1,600.00
$1,072.00
Free shipping over $300 Free Shipping
Technical Support Technical Support
3 Year Warranty 3 Year Warranty

Description

Bosch DVR-650-08A050 8-channel Digital Video Recorder (500GB)

The Bosch DVR-650-08A050 8-channel Digital Video Recorder (500GB) utilizes the H.264 compression technology to reduce the size of the video files without sacrificing the image quality and resolution. It offers a resolution of up to 1440 x 900 pixels and has search and playback functions to let you quickly access the recorded videos. This video recorder with is built-in DVD writer is capable of recording multiple video and audio signals and starts functioning automatically when the cameras are connected. It enables live multi-screen viewing and playback simultaneously and its two monitor outputs provide full-screen, quad and multi-screen viewing modes.&

This DVR-650-08A050 video recorder has a built-in web application that enables live viewing, playback and configuration. The integrated Control Center PC software lets you easily control the DVR over a network. This Bosch DVR-650-08A050 8-channel Digital Video Recorder (500GB) features an archive player for viewing secure video files and offers authenticity check for both local and remote playback to maintain the recording integrity. Its Real Time Streaming Protocol (RTSP) easily configures the suitable mobile devices and let them display live video streamed by the DVR over the internet.

Key Features:

  • DVD Writer: lets you write the video footages on DVDs&
  • Rear Panel: with looping auto-terminating video inputs and outputs, audio inputs and outputs and alarm inputs and outputs
  • 500GB Storage: for archiving tons of videos or footages
  • On-screen Display Menu: for easy operation and programming of the DVR
  • Embedded Design: reduces maintenance and operational costs
  • Control Center PC Software: allows you to control the DVR over a network

Bosch DVR-650-08A050 8-channel Digital Video Recorder (500GB) Specifications

  • Operating system: Windows XP, Windows Vista or Windows 7
  • Web browser: Internet Explorer 7, 8 or 9
  • Processor: Intel Core Duo 2.0 GHz or comparable
  • RAM memory: 2048 MB
  • Free disk space: 10 MB
  • Graphics card: NVIDIA GeForce 8600 or better
  • Video memory: 256 MB
  • Network interface: 10/100-BaseT
  • External power adapter AC input: 110-240 VAC; 50/60 Hz; 1.8 A
  • External power adapter DC output: 12 VDC; 5 A
  • DVR Power input: 12 VDC; 3.5 A; 145 BTU/h
  • Inputs: Composite video 1 Vpp, 75 ohm, automatic termination; PAL / NTSC auto-detect
  • AGC: Automatic gain adjustment for each video input
  • Hard Disks: Supports up to 2 SATA hard drives maximum 2TB each
  • Record Rate (IPS) NTSC: Max. 30 IPS per channel, configurable: 30, 15, 7.5, 5, 3, 1
  • Record Rate (IPS) PAL: Max. 25 IPS per channel, configurable: 25, 12.5, 6.25, 5, 2.5, 1
  • Recording Quality: Best, High, Normal, Low, Lowest
  • Average Recording Capacity CIF, Normal, 25/30 IPS: PAL-138 hours, NTSC-170 hours
  • Average Recording Capacity CIF, Normal, 6.25/7.5 IPS: PAL-350 hours, NTSC-425 hours
  • Average Recording Capacity 2CIF, Normal, 12.5/15 IPS: PAL-115 hours, NTSC-144 hour
  • Average Recording Capacity 4CIF, Normal, 6.25/7.5 IPS: PAL- 93 hours, NTSC-115 hours
  • Maximum recording rates Local 16 channels 4CIF: PAL-6 IPS, NTSC-7.5 IPS
  • Maximum recording rates Local 16 channels 2CIF: PAL-12.5 IPS, NTSC- 15 IPS
  • Maximum recording rates Local 16 channels CIF: PAL-25 IPS, NTSC-30 IPS
  • Maximum recording rates Local 8 channels 4CIF: PAL-12.5 IPS, NTSC-15 IPS
  • Maximum recording rates Local 8 channels 2CIF: PAL-25 IPS, NTSC-30 IPS
  • Maximum recording rates Local 8 channels CIF: PAL-25 IPS, NTSC-30 IPS
  • Maximum recording rates Local 4 channels 4CIF: PAL-12.5 IPS, NTSC-15 IPS
  • Maximum recording rates Local 4 channels 2CIF: PAL-25 IPS, NTSC-30 IPS
  • Maximum recording rates Local 4 channels CIF: PAL-25 IPS, NTSC-30 IPS
  • Remote (network) 16 channels CIF: PAL-6.75 IPS, NTSC-7.5 IPS
  • Remote (network) 8 channels CIF: PAL-12.5 IPS, NTSC-15 IPS
  • Video Outputs Monitor: A-VGA RGB, Monitor B-VGA RGB
  • Live Resolution (Mon.A): 800x600 (4:3), 1024x768 (4:3), 1280x1024 (5:4), 1366x768 (16:9), 1440x900 (16:10)
  • Digital Zoom: 2 times
  • Streaming video: H.264 compression
  • Audio Inputs: Mono RCA, 1.0 Vpp
  • Audio Output: Mono RCA, 1.0 Vpp
  • Compression: ADPCM
  • Sample rate: 16 kHz per channel
  • Bit rate: 8-bit
  • Inputs: 8 or 16 inputs configurable NO/NC, max. input voltage 15 VDC
  • Outputs: 4 Relay outputs, configurable NO/NC, max. rated 30 VAC, 40 VDC 0.5 A continuous or 10 VA
  • RS485: Output signals according to RS485, max. signal voltage -8 to +12 V
  • RS485 Support: Bosch domes, and Pelco P and D
  • Video Inputs: 8 or 16 looping BNC, auto termination
  • Monitor: 2 VGA D-SUB
  • Alarm connectors: Screw terminal inputs, cable diameter AWG26‑16 (0.13-1.5 mm)
  • Audio Inputs: 4 RCA (CINCH)
  • Audio Output: 2 RCA (CINCH)
  • Ethernet: RJ45, 10/100 BaseT according to IEEE802.3
  • RS485: Screw terminal output, cable diameter AWG28‑16 (0.08-1.5 mm)
  • USB 2.0: One front and one rear USB connector for mouse or USB memory device
  • Display Modes Monitor A: Full, quad, multi-screen (live and playback), full sequence, alarm call-up (live)
  • Display Modes Monitor B: Full, quad, multi-screen, full sequence, alarm call-up (live)
  • Normal partition: Continuous recording (with or without overwriting)
  • Event partition: Input and motion recording (with or without overwriting)
  • Dimensions (WxDxH): 355 x 362 x 78 mm (13.9 x 14.2 x 3.1 in) excluding cabling
  • Weight: 4.3 kg (9.46 lb) approx.
  • Temperature Operating: +0°C to +40°C (+32°F to +104°F)
  • Temperature Storage: -40°C to +70°C (-40°F to +158°F)
  • Humidity Operating: <93% non-condensing
  • Humidity Storage: <95% non-condensing

View AllClose

Additional Information

Channel Capacity:
16 camera channels
NDAA Compliant:
Recorder Technology:
Digital Video Recorder (DVR)
Warranty:
3-year Manufacturer Warranty
