Bosch NEI-308V05-23WE Dinion IP Infrared Day/Night Imager - 540TVL, 850nm, NTSC, 5~50mm Varifocal Lens, H.264, IEEE 802.3at, class 4 compliant

NEI-308V05-23WE
Save
88%
Bosch NEI-308V05-23WE Dinion IP Infrared Day/Night Imager - 540TVL, 850nm, NTSC, 5~50mm Varifocal Lens, H.264, IEEE 802.3at, class 4 compliant
Hover on image to enlarge
$4,400.00
$521.52
You save: $3,878.48 (88%)



This item has been discontinued and is not in stock. Below is the suggested replacement. Please contact us by phone, chat, or email to confirm compatibility. .

  • Shipping Policy
  • Return Policy
  • Ask Question
Delivery
Payment options
fingerprintOur advantages

person Dedicated StaffDedicated Staff

people Free Presales SupportFree Presales Support

palette Free DesignFree Design

label_outline Best priceWe are proud of our prices, hundreds of customers check them every day, which give a choice to our online store!

Description

Bosch NEI-308V05-23WE

The Bosch NEI-308V05-23WE Dinion IP Infrared Day/Night Imager (850 nm, NTSC), with a 1/3″ wide dynamic range CCD sensor, records footage at a resolution of 704 x 480 (4CIF) at 30 ips. The 5 to 50mm varifocal lens enables recording of clear images throughout the field of view. Dinion2X technology, along with the 20-bit digital signal processing, enables excellent clarity levels by exposing the tiniest details in the captured images. The camera’s Infrared Imager features advanced technologies that enhance performance. Variable Field Illumination allows IR beam pattern adjustments in the field, enabling the entire field of view (foreground and background included) to be evenly illuminated for excellent performance in low-light and zero lux conditions. The imager utilizes Constant Light technology that employs closed loop feedback to control infrared performance. H.264 technology enables optimal usage of the available bandwidth and storage space.&

Simultaneous tri-streaming is possible on 2 H.264 streams and an M-JPEG stream. When connected to the network, the imager can directly stream footage to an NVR or an iSCSI target for storage. The recorded videos can be conveniently viewed on a PC via a web browser, with the Bosch Video Management System, or with VIDOS. An integrated junction box can be pre-installed to minimize the installation time. IP-based control and configuration assist easy set-up. The robust aluminum housing of this Infrared Imager has been NEM A4X weather-sealed and IP67-rated, ensuring protection from dust, rain, and corrosion when installed outdoors. The unit is specially designed for round- the -clock perimeter surveillance.

Key Features of The Bosch NEI-308V05-23WE

  • Infrared
  • Day/Night
  • 704x480 Resolution
  • 5-50mm Varifocal Lens
  • H.264 Encoding
  • Weather and Vandal Proof
Features

Manufacturer:
Bosch
Product Type:
Cameras
Warranty:
3-year Manufacturer Warranty
Discontinued:
no

Security Camera Features

Lens Size:
5~50mm
Resolution:
540TVL
Sensor Size:
1/3"
Camera Style:
  • Bullet
Technical Specs

Bosch NEI-308V05-23WE Specifications

  • Specialized for perimeter surveillance and other outdoor low-light applications
  • Range of up to 525' (160 m) in both day and night conditions
  • 1/3" CCD sensor and 5 to 50mm IR-corrected varifocal auto-iris lens allow for recording of sharp and lucid images throughout field of view
  • DINION 2X technology and 20-bit digital signal processing for exposing the tiniest details of images captured in varying lighting conditions
  • Variable Field Illumination allows IR beam pattern adjustments in the field, which enables both the foreground and background to be evenly illuminated for superb performance in low-light as well as zero lux conditions
  • Constant Light technology uses closed loop feedback to control infrared performance throughout the service life of the IR imager
  • Privacy masking for concealing up to 4 zones in the recording frame for shielding sensitive areas in the camera's surveillance range
  • Video motion detection is programmable to be active in any single part of the recording frame - perfect for high-risk areas
  • MOTION+ video motion analysis system allows for object size filtering and tamper detection
  • IVA (Intelligent Video Analysis) digital imaging technology algorithm uses multi-level image analysis of pixels, texture, and object direction for advanced video analytics functionalities
  • H.264 compression and bandwidth throttling for effective bandwidth and storage utilization without affecting the quality of the images
  • Simultaneous tri-streaming on 2 H.264 streams and 1 MJPEG stream
  • Directly records footage on to Network Video Recorders of iSCSI targets when connected to the network
  • Multiple ways to stream footage on a PC using a web browser, with the Bosch Video Management System, or with VIDOS
  • Compliant with the ONVIF standard, which ensures interoperability with other ONVIF-compliant products from different manufacturers
  • IP-based control and configuration makes setup easy and quick
  • Integrated junction box and sunshield
  • Integrated on-screen display (OSD) and complete external adjustments further simplify installation
  • Up to 3 different power options to choose from including PoE+ (Power over Ethernet+), 12 VDC, and 24 VAC
  • Weather-sealed IP67-rated aluminum housing shields it from dust, rain, and corrosion when installed outdoors
  • IK10-rated cameras ensures uninterrupted surveillance even when installed in high-risk locations
Datasheets

Specsheet (bosch-NEI_30_Data_sheet_enUS_2233681419-A1.pdf, 1,447 Kb) [Download]
