Description
Dahua 1A404XBNR 4MP Outdoor Mini PTZ IP Security Camera with 2.8~12mm Lens, WizSense Series
The 4 MP IR Mini PTZ Dome camera features a 1/2.8-in. STARVIS™ CMOS imager with a 4x optical zoom lens. The camera uses the Smart H.265+ video compression standard to improve encoding efficiency while preserving high-quality video. The PTZ camera uses a day/night mechanical IR cut filter and True WDR to deliver crystal clear images in challenging lighting conditions.
Dahua Analytics+ includes Tripwire and Intrusion functions that offer custom tripwires based on object type for automation in limited access areas. Perimeter Protection requires less pixels to detect an object to deliver improved accuracy and decreased false alarms due to lights, weather, trees, or animals. In addition, the camera uses complex real-time people counting algorithms to deliver accurate flow statistics from two distinct people counting functions, Line Crossing and Regional.
Smart Motion Detection improves alarm accuracy and decreases the number of false alarms. The advanced SMD algorithm analyzes a scene for human or vehicle motion, while filtering out other motion due to trees, leaves, animals, weather, and triggers an alarm when detected. SMD also saves time when searching recorded video by filtering false alarms and allowing quick retrieval of an alarm due to a person or vehicle.
Key Features:
- 1/2.8-in. 4 MP STARVIS™ CMOS Sensor
- 4x Optical Zoom
- Starlight Technology for Low Light Sensitivity
- Triple-stream Encoding
- Smart H.265+ and Smart H.264+ Dual Codecs
- 4 MP at 30 fps Maximum Resolution
- True Wide Dynamic Range (120 dB)
- Analytics+ Function – Perimeter Protection, People Counting, Smart Motion Detection, and Face Detection
- Maximum IR Distance 15 m (49 ft)
- IP66 Ingress Protection and IK08 Vandal Resistance
- Five-year Warranty
Downloads
Compatible products
Additional Information
|
Analytics:
|
Analytics+ Function
Smart Motion Detection+
People Counting
Face Detection
Line Crossing
Perimeter Protection
|
|
Aperture:
|
F1.8
F2.7
|
|
Audio Capability:
|
Two-Way Audio
|
|
Audio Compression:
|
G.711a
G.711Mu
G.726
G.722.1
G.729
G.723
MPEG2-L2
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Built-in Features:
|
Built-in Analytics
|
|
Camera Style:
|
Mini PTZ
|
|
Certifications:
|
FCC
|
|
Color:
|
White
|
|
Compatible Integration (API):
|
ONVIF
CGI Conformant
|
|
Compression:
|
H.265
Smart H.265 Plus
H.264 Plus
H.264B
H.264M
H.264H
MJPEG
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
Day (Color)
Night (B/W)
ICR (True Day/Night)
Auto
|
|
Detect (ft):
|
482.28
|
|
Digital Zoom:
|
16
|
|
Dimensions:
|
128 x 65.40 mm (5.04 x 2.57 in)
|
|
Durability:
|
Weatherproof
Vandal Resistant
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
96.9
31.6
|
|
Focus:
|
Semi-Auto
Manual
Auto Focus
|
|
Identify (ft):
|
48.23
|
|
Iris:
|
Auto
|
|
Lens Size:
|
2.8~12mm
|
|
Lens Type:
|
Motorized (Automatic Zoom) Lens
|
|
Max Power Consumption:
|
8.5 Watts
|
|
Max. FPS and Resolution:
|
30fps at 2560 x 1440
|
|
Max. Storage Capacity:
|
256 GB
|
|
Minimum Illumination (B/W):
|
0 lux
|
|
Minimum Illumination (Color):
|
0.005 Lux
|
|
Mobile Apps:
|
iOS
Android
|
|
Mounting:
|
Ceiling Mount
Pendant Mount
Pole Mount
Corner Mount
Wall Mount
|
|
Network Interface:
|
1x Rj-45 10/100 Base-T
|
|
Night Vision Range (ft):
|
49
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Noise Reduction:
|
2D DNR
3D DNR
|
|
Observe (ft):
|
192.91
|
|
Optical Zoom:
|
4x Optical Zoom
|
|
Power Supply:
|
12 VDC
PoE (IEEE 802.3af)
|
|
Product Series:
|
Dahua Lite Series
Dahua WizSense Series
|
|
Protection Code:
|
IP66
IK08
|
|
RAM:
|
1GB
|
|
Recognize (ft):
|
96.46
|
|
Remote Users:
|
Up to 20
|
|
Resolution:
|
4MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.8"
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1-1/30000s
|
|
Special Technologies:
|
Dahua Starlight Technology
|
|
Surge Protection:
|
TVS 6000V
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
5-year Manufacturer Warranty
|
|
Wavelength (nm):
|
850
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
