Dahua N44CL52 4MP IR H.265+ ePoE Outdoor Dome IP Security Camera with 2.8mm Fixed Lens

Dahua N44CL52 4MP IR H.265+ ePoE Outdoor Dome IP Security Camera with 2.8mm Fixed Lens

The 4 MP mini dome camera features an advanced 1/3-in. Progressive-scan imager with a 3.6 mm fixed lens. The camera offers True Wide Dynamic Range, a True Day/Night IR Cut filter, IP67 Ingress Protection and operation in extreme temperatures to deliver superior images in all lighting and environmental conditions. The camera is a component of Dahua's innovative Enhanced Power over Ethernet (ePoE) system that transmits power and data over long distances without the need for repeaters or multiple switches.

Key features:

• 1/3-in. 4 MP Progressive-scan CMOS Sensor
• Triple Stream Encoding
• Smart H. 265+ and H.264 Dual Codecs
• 4 MP at 30 fps Maximum Resolution
• 2.8 mm Fixed Lens
• Enhanced Power and Data Transmission Distances with ePoE
• True WDR (120 dB) and True Day/Night (ICR)
• Maximum IR LED Length 30 m (98ft) with Smart IR
• IP67 Ingress Protection and IK10 Vandal Resistance
• Intelligent Video System
• Five-year Warranty (for products sold through an authorized Dahua Dealer)

Enhanced Power over Ethernet (ePoE) Technology

Dahua's innovative ePoE technology offers a plug-and-play solution to transmit power and data over long distances via Ethernet or coaxial cables, reducing installation time and saving money. ePoE technology is a viable, cost-effective solution for extending transmission distances and for converting existing, coax-based analog systems into IP systems. For video security and surveillance installers, ePoE technology saves time and money by reducing overall cabling requirements, allowing for existing coax cable to be used, and minimizing the number of peripheral devices needed. For new installations, ePoE offers the ability to design long-distance applications without the need for additional repeaters. Enhanced PoE encompasses pure IP systems where a single CAT 5 cable can carry signals up to 800 m (2624ft), and IP/Analog hybrid systems where the technology leverages existing analog infrastructure to transmit power and data up to 1000 m (3281ft) over RG59 coaxial cable. Enhanced PoE is compatible with three connection modes operating over the same network simultaneously: traditional IP networks, long-distance ePoE networks and coaxial networks. ePoE technology seamlessly integrates the latest high-definition IP cameras with a coaxial infrastructure using the Ethernet over Coaxial (EoC) protocol to convert between analog and IP power and data transmissions.

True Wide Dynamic Range (WDR)

The camera achieves vivid images, even in the most intense contrast lighting conditions, using industry-leading wide dynamic range (WDR) technology. For applications with both bright and low lighting conditions that change quickly, True WDR (120 dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video.

Intelligent Video System (IVS)

IVS is a built-in video analytic algorithm that delivers intelligent functions to monitor a scene for Tripwire violations, intrusion detection, and abandoned or missing objects. A camera with IVS quickly and accurately responds to monitoring events in a specific area. In addition to scene analytics, the camera offers tamper detection by recognizing a dramatic scene change and generating a warning message to inspect the camera.

Smart H.265+

Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ technology reduces bit rate and storage requirements by up to 70% when compared to standard H.265 video compression.

Environmental

Dahua cameras operate in extreme temperature environments, rated for use in temperatures from –30° C to +60° C (–22° F to +140° F) with 95% humidity. The camera complies with the IK10 impact rating and is certified to rigorous dust and immersion tests (IP67), making the camera the choice for installation in even the most unforgiving environments.

Accessories:

• Wall Mount Bracket PFB203W
• Junction Box PFA136
• Sun/Rain Shield PFA200W
• 12 VDC, 1 A Power Adapter DH-PFM321D-US
• EoC Passive Converter LR1002
• Single-port EoC Receiver LR1002-1EC
• Pole Mount Bracket PFA152-E
