Description
Dahua N85FF62 8MP IR Outdoor Bullet IP Security Camera with 2.8mm Fixed Lens and Analytics+
The Dahua AcuPick Starlight+ 8MP Network Bullet Camera offers Analytics+ functions at the edge–performing complex real-time AcuPick, Face Detection, People Counting, and Perimeter Protection. Dahua's Analytics+ algorithms significantly improve accuracy and reliability compared to standard intelligent features. The camera is ideal for a host of diverse applications with Starlight+, Ultra Wide Dynamic Range, and Smart IR technologies and an IP67 and IK10 rating to allow the camera to operate in the most difficult lighting conditions and environments.
Key Features:
- 1/1.8-in. 8MP Progressive-scan CMOS Sensor
- Quadruple-stream Encoding
- AI Coding, Smart H.265+, and Smart H.264+ Video Compression
- AI Smart Scene Adaptive (SSA) Technology
- 8MP (3840 x 2160) at 30 fps, 2.8 mm Fixed Lens
- Enhanced Power and Data Transmission Distances (ePoE)
- Starlight+ Technology for Low-light Applications
- Analytics+ Functions — AcuPick, Face Detection, People Counting, Perimeter Protection, and Smart Motion Detection+
- True Wide Dynamic Range (120 dB) and True Day/Night IR Cut Filter
- Maximum IR LED Distance 50 m (164.04 ft)
- Built-in Microphone
- IP67 Ingress Protection, IK10 Vandal Resistance
- Five-year Warranty
Downloads
Datasheet
Dahua-N85FF62-Datasheet-A1
User Manual
Dahua-N85FF62-User-Manual-A1
Document
FAQs-and-Troubleshooting
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Alarm Input:
|
1 Channel
|
|
Alarm Output:
|
1 Channel
|
|
Alternative SKUs:
|
VD-N85FF62
|
|
Analytics:
|
Analytics+ Function
Face Detection
People Counting
Perimeter Protection
Smart Motion Detection+
Heat Map
|
|
Aperture:
|
F1.6
|
|
Audio Compression:
|
PCM
G.711a
G.711Mu
G.726
G.723
AAC
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Audio Support:
|
Built-in Microphone
|
|
Camera Style:
|
Bullet
|
|
Certifications:
|
FCC
|
|
Color:
|
White
|
|
Compatible Integration (API):
|
ONVIF Profile G
ONVIF Profile S
ONVIF Profile T
CGI Conformant
P2P
|
|
Compression:
|
AI Coding
Smart H.265 Plus
H.265
Smart H.264 Plus
H.264
H.264B
H.264H
MJPEG
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
Auto
Day (Color)
Night (B/W)
ICR (True Day/Night)
|
|
Detect (ft):
|
293
|
|
Dimensions:
|
244.1 x 79 x 75.9 mm (9.61 x 3.11 x 2.99 in)
|
|
Durability:
|
Weatherproof
Vandal Proof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Diagonal):
|
134
|
|
Field of View (Horizontal):
|
110
|
|
Field of View (Vertical):
|
57
|
|
IR LED Quantity:
|
4
|
|
Identify (ft):
|
29
|
|
Image Enhancements:
|
Backlight Compensation (BLC)
Highlight Compensation (HLC)
Defog
|
|
Lens Mount:
|
M16
|
|
Lens Size:
|
2.8mm
|
|
Lens Type:
|
Fixed Lens
|
|
Main Stream:
|
8MP
|
|
Material:
|
Metal
|
|
Max Power Consumption:
|
9.8 Watts
|
|
Max. FPS and Resolution:
|
30fps at 3840 x 2160 (4K)
|
|
Max. Storage Capacity:
|
512 GB
|
|
Minimum Illumination (B/W):
|
0.0004 Lux
0 lux with IR illumination on
|
|
Minimum Illumination (Color):
|
0.0008 Lux
|
|
Network Interface:
|
1x Rj-45 10/100 Base-T
|
|
Night Vision Range (ft):
|
164.04
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Noise Reduction:
|
3D DNR
|
|
Observe (ft):
|
117
|
|
Power Supply:
|
ePoE
PoE (IEEE 802.3af)
12 VDC
|
|
Product Series:
|
Dahua Pro Series
Dahua WizMind Series
Dahua AcuPick Series
|
|
Protection Code:
|
IP67
IK10
|
|
RAM:
|
2GB
|
|
ROM:
|
4GB
|
|
Recognize (ft):
|
58
|
|
Region of Interest (ROI):
|
4
|
|
Remote Users:
|
Up to 20
|
|
Resolution:
|
8MP (4K)
|
|
S/N Ratio:
|
>56 dB
|
|
SD Card Support:
|
SD Card Supported
|
|
Security:
|
IP address filtering
Password protection
HTTPS encryption
|
|
Sensor Size:
|
1/1.8"
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/3-1/100000s
|
|
Special Technologies:
|
Dahua AcuPick Technology
|
|
Specialized Camera Feature:
|
Deep-learning
|
|
Storage Temperature:
|
-40 °C to 60 °C (-40 °F to 140 °F)
|
|
Sub Stream:
|
D1
|
|
Technology:
|
Network (IP)
|
|
Third Stream:
|
1080P
|
|
Warranty:
|
5-year Manufacturer Warranty
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
|
ePoE Technology:
|
ePoE Technology
|
