Description
Hikvision DS-2CD2125G0-IMS(2.8MM) Performance Series 2MP Indoor IR Dome IP Security Camera, 2.8mm Fixed Lens, White
Hikvision’s DS-2CD2125G0-IMS 2 MP IR Fixed Dome Indoor Network Camera provides HDMI output directly to a video display to conveniently set up a public view monitor (PVM) for theft deterrence. The camera offers 1920 x 1080 resolution at 60 fps, and comes with a 2.8 mm, 4 mm, or 6 mm fixed lens.
Color sensitivity is down to 0.009 lux at ƒ/1.6 (0 lux with IR having a 98-foot (30 meter) range), and true 120 dB WDR for high quality images. BLC, 3D DNR, ROI, and HLC add to getting the best image.
Four behavior analyses and face detection help identify suspicious activity, and a built-in microSD card slot supports up to 128 GB.
Key Features:
- Color: 0.009 Lux @ (ƒ/1.6, AGC on), 0 Lux with IR
- 1920 × 1080 @ 60 fps
- 2.8 mm/4 mm/6 mm Fixed Lens
- H.265, H.264
- Main Stream: 60 Hz: 60 fps (1920 × 1080, 1280 × 720)
- 98 ft (30 m) IR Range
- Powered by DarkFighter
- 1/2.8" Progressive Scan CMOS
- HDMI Output
- 120 dB WDR
- 4 Behavior Analyses and Face Detection
- BLC/3D DNR/ROI/HLC
- IK10
- Built-in MicroSD/SDHC/SDXC Slot, up to 128 GB
- 3-Axis Adjustment
Downloads
Quick Start Guide
Hikvision-DS-2CD2125G0-IMS(2.8MM)-Quick-Start-Guide-A1
Firmware
Firmware:-IPC_G1_EN_STD_5.6.6_210625
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Alarm Input:
|
1 Channel
|
|
Alarm Output:
|
1 Channel
|
|
Alternative SKUs:
|
DS-2CD2125G0-IMS
HX-OD2125MS2
DS-2CD2125G0-IMS 2.8MM
|
|
Analytics:
|
Line Crossing
Face Detection
Intrusion Detection
|
|
Aperture:
|
F1.6
|
|
Audio Compression:
|
G.711
G.722.1
G.726
MP2L2
PCM
MP3
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Camera Style:
|
Dome
|
|
Certifications:
|
cULus
CE
FCC
|
|
Color:
|
White
|
|
Compatible Integration (API):
|
ONVIF Profile G
ONVIF Profile S
ISAPI
SDK
|
|
Compression:
|
H.265
H.264
MJPEG
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
ICR (True Day/Night)
|
|
Dimensions:
|
119 x 90 mm (4.7 x 3.5 in)
|
|
Durability:
|
Vandal Proof
|
|
Environmental:
|
Indoor
|
|
Field of View (Diagonal):
|
128
|
|
Field of View (Horizontal):
|
108
|
|
Field of View (Vertical):
|
58
|
|
Image Enhancements:
|
Auto Gain Control (AGC)
Backlight Compensation (BLC)
Highlight Compensation (HLC)
|
|
Image Settings:
|
Mirror
Privacy Mask
Brigthness
Contrast
Saturation
Sharpness
|
|
Languages:
|
English
Russian
Estonian
Bulgarian
Hungarian
Greek
German
Italian
Czech
Slovak
French
Polish
Dutch
Portuguese
Spanish
Romanian
Danish
Swedish
Norwegian
Finnish
Croatian
Slovenian
Serbian
Turkish
Korean
Traditional Chinese
Thai
Vietnamese
Japanese
Latvian
Lithuanian
Portuguese (Brazil)
|
|
Lens Mount:
|
M12
|
|
Lens Size:
|
2.8mm
|
|
Lens Type:
|
Fixed Lens
|
|
Main Stream:
|
1080P
|
|
Material:
|
Metal
|
|
Max Power Consumption:
|
8.5 Watts
|
|
Max. FPS and Resolution:
|
60fps at 1920 x 1080
|
|
Max. Storage Capacity:
|
128 GB
|
|
Minimum Illumination (B/W):
|
0 lux with IR illumination on
|
|
Minimum Illumination (Color):
|
0.009 Lux at F1.6 AGC On
|
|
Network Interface:
|
1x RJ-45 10M/100M self-adaptive Ethernet interface
|
|
Night Vision Range (ft):
|
98
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Noise Reduction:
|
3D DNR
|
|
Power Supply:
|
12 VDC
PoE (IEEE 802.3af)
|
|
Privacy Mask:
|
4 area
|
|
Product Series:
|
Hikvision Performance Series
|
|
Protection Code:
|
IP42
IK10
|
|
Region of Interest (ROI):
|
1
|
|
Remote Users:
|
Up to 32
|
|
Reset Button:
|
|
|
Resolution:
|
2MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Security:
|
Digest authentication
IP address filtering
Password protection
|
|
Sensor Size:
|
1/2.8"
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/3-1/100000s
|
|
Sub Stream:
|
VGA
|
|
Technology:
|
Network (IP)
|
|
Wavelength (nm):
|
850
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
