Description
Hikvision DS-2CD2563G0-IS 4MM 6MP Night Vision H.265+ Outdoor Mini Dome IP Security Camera
The Hikvision DS-2CD2563G0-IS Outdoor IR Fixed Mini Network Dome Camera provides high definition network output. It supports H.265+ video compression, which assures savings in bandwidth and storage.
The camera is equipped with 2.8 mm and 4 mm fixed lens options, and offers an EXIR 2.0 range of up to 35ft (10 m).
Smart features, such as line crossing and intrustion detection are supported.
Key Features:
- 1/2.9" (6 MP) Progressive Scan CMOS
- 3072 x 2048 Resolution @ 30 fps
- 2.8 mm Fixed Lens, horizontal field of view: 97°
- EXIR 2.0 Range Up to 35ft (10 m)
- H.265+, H.265, H.264+, H.264
- 120dB True WDR
- MicroSD Card Slot Supports 128 GB
- IP66, IK08 Protection
- 12 VDC and PoE (802.3af)
- Minimum Illumination: Color: 0.028 lux @ (f/2.0, AGC on), 0 Lux with IR
- Main Stream: 20 fps (3072 x 2048, 3072 x 1728, 2944 x 1656), 30fps (2560 x 1440, 1920 x 1080, 1280 x 720)
Downloads
Quick Start Guide
Hikvision-DS-2CD2563G0-IS-4MM-Quick-Start-Guide-A1
User Manual
Hikvision-DS-2CD2563G0-IS-4MM-User-Manual-A1
Firmware
Firmware:-IPC_G1_EN_STD_5.6.6_210625
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Alarm Input:
|
1 Channel
|
|
Alarm Output:
|
1 Channel
|
|
Alternative SKUs:
|
DS-2CD2563G0-IS
DS-2CD2563G0-IS(4MM)
HX-CD2563F4
|
|
Analytics:
|
Line Crossing
Intrusion Detection
|
|
Aperture:
|
F2.0
|
|
Audio Compression:
|
G.711alaw
G.711ulaw
G.722.1
G.726
MP2L2
PCM
|
|
Audio Input:
|
2x Channel
|
|
Audio Output:
|
1x Channel
|
|
Audio Support:
|
Built-in Microphone
|
|
Camera Style:
|
Mini Dome
|
|
Certifications:
|
cULus
CE
FCC
|
|
Color:
|
White
|
|
Compatible Integration (API):
|
ISAPI
ONVIF Profile G
ONVIF Profile S
|
|
Compression:
|
H.264
H.264 Plus
H.265
H.265 Plus
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
ICR (True Day/Night)
|
|
Dimensions:
|
110 x 56.4 mm (4.3 x 2.2 in)
|
|
Durability:
|
Vandal Proof
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Diagonal):
|
98
|
|
Field of View (Horizontal):
|
78
|
|
Field of View (Vertical):
|
53
|
|
Focus:
|
Manual
|
|
Image Enhancements:
|
Auto Gain Control (AGC)
Backlight Compensation (BLC)
Highlight Compensation (HLC)
|
|
Image Settings:
|
Brigthness
Contrast
Saturation
Sharpness
|
|
Lens Mount:
|
M12
|
|
Lens Size:
|
4mm
|
|
Lens Type:
|
Fixed Lens
|
|
Main Stream:
|
6MP
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Material:
|
Metal
Plastic
|
|
Max Power Consumption:
|
8.5 Watts
|
|
Max. FPS and Resolution:
|
20fps at 3072 x 2048
|
|
Max. Storage Capacity:
|
128 GB
|
|
Minimum Illumination (B/W):
|
0 lux with IR illumination on
|
|
Minimum Illumination (Color):
|
0.028 lux at F2.0 AGC ON
|
|
Network Interface:
|
1x RJ-45 10M/100M Base-TX Ethernet
|
|
Night Vision Range (ft):
|
35
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Noise Reduction:
|
3D DNR
|
|
Power Supply:
|
12 VDC
PoE (IEEE 802.3af)
|
|
Protection Code:
|
IK08
IP66
|
|
Remote Users:
|
Up to 32
|
|
Reset Button:
|
|
|
Resolution:
|
6MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.9"
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/3-1/100000s
|
|
Storage Humidity:
|
0% to 95% RH (non-condensing)
|
|
Storage Temperature:
|
-30 °C to 60 °C (-22 °F to 140 °F)
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Wavelength (nm):
|
850
|
|
Web Browser:
|
Chrome 41.0 to 44
Firefox 30.0 to 51
Firefox 52.0 or above
Internet Explorer 8 or above
Safari 8 to 11
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
