Description
Hikvision DS-2CD6D52G0-IHS 4MM 5MP Night Vision Multi-sensor IP Security Camera, PanoVu, Dual-Directional, H.265+
The Hikvision PanoVu DS-2CD6D52G0-IHS Dual- Directional PanoVu Camera features a dual-lens design to capture two separate wide angle views. Other features include H.265+ video compression, audio I/O, an internal microSD memory card slot (up to 256 GB), and an IR range of up to 33 feet (10 meters).
Key Features:
- Minimum Illumination Color: 0.009 lux @ (f/1.6, AGC on), B/W: 0.0018 lux @ (f/1.6, AGC on), 0 lux with IR
- 2560 x 1920 @ 30 fps
- Flexible Lens: P: -90° to 90°; T: 0° to 60° (2.8mm), 0° to 70° (4 mm/6 mm); R: 0° to 355
- Compressions: H.265+, H.265, H.264+, H.264
- Frame Rate: Main Stream 30 fps (2560 × 1920, 2048 × 1536)
- Built-in MicroSD/SDHC/SDXC Card Slot, up to 256 GB
- 12 VDC, POE (802.3af)
- Weatherproof IP67
- Vandal Proof IK10
Downloads
Additional Information
|
Alarm Input:
|
1 Channel
|
|
Alarm Output:
|
1 Channel
|
|
Analytics:
|
Motion Detection
Tampering
|
|
Aperture:
|
F1.6
|
|
Audio Capability:
|
Two-way Audio
|
|
Audio Compression:
|
G.711
G.722.1
G.726
MP2L2
PCM
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Audio Support:
|
Built-in Microphone
|
|
Built-in Features:
|
Built-in Heater
|
|
Camera Style:
|
Multi-sensor
|
|
Certifications:
|
FCC
UL Listed
CB
REACH
WEEE
|
|
Color:
|
White
|
|
Compatible Integration (API):
|
ONVIF Profile S
ONVIF Profile G
ONVIF Profile T
ISAPI
|
|
Compression:
|
H.265
H.265 Plus
H.264 Plus
H.264
MJPEG
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
ICR (True Day/Night)
|
|
Dimensions:
|
164.3 x 84.6 x 67.4 mm (6.5 x 3.3 x 2.7 in)
|
|
Durability:
|
Weatherproof
Vandal Proof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
79
|
|
Image Enhancements:
|
Auto Gain Control (AGC)
Backlight Compensation (BLC)
Defog
Electronic Image Stabilization (EIS)
Highlight Compensation (HLC)
|
|
Image Settings:
|
Brigthness
Contrast
Mirror
Privacy Mask
Saturation
Sharpness
|
|
Languages:
|
English
Turkish
French
German
Bulgarian
Croatian
Czech
Danish
Dutch
Estonian
Finnish
Greek
Hungarian
Italian
Japanese
Korean
Latvian
Lithuanian
Norwegian
Polish
Portuguese
Portuguese (Brazil)
Romanian
Russian
Serbian
Slovak
Slovenian
Spanish
Swedish
Thai
Traditional Chinese
Vietnamese
|
|
Lens Mount:
|
M12
|
|
Lens Size:
|
4mm
|
|
Lens Type:
|
Fixed Lens
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Material:
|
Metal
|
|
Max Power Consumption:
|
11 Watts
|
|
Max. FPS and Resolution:
|
30fps at 2560 x 1920
|
|
Max. Storage Capacity:
|
256 GB
|
|
Minimum Illumination (B/W):
|
0 lux with IR illumination on
0.0018 lux at F1.6 AGC on
|
|
Minimum Illumination (Color):
|
0.009 lux
|
|
Network Interface:
|
1x RJ-45 10M/100M Base-TX Ethernet
|
|
Night Vision Range (ft):
|
33
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Noise Reduction:
|
3D DNR
|
|
Power Supply:
|
12 VDC
PoE (IEEE 802.3af)
|
|
Product Series:
|
Hikvision Smart Series
Hikvision PanoVu Series
|
|
Protection Code:
|
IP67
IK10
|
|
Region of Interest (ROI):
|
4
|
|
Remote Users:
|
Up to 32
|
|
Reset Button:
|
|
|
Resolution:
|
5MP (3K)
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.7"
|
|
Sensor Type:
|
CMOS
|
|
Serial Interface:
|
1x RS485
|
|
Shutter Speed:
|
1-1/100000s
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
5-year Manufacturer Warranty
|
|
Wavelength (nm):
|
850
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
