Hikvision DS-2CD6W32FWD-IVS 3MP IR Outdoor Ultra-wide Angle Panoramic IP Security Camera
Key features:
- 3 megapixel image sensor
- 1/3″ Progressive Scan CMOS
- 2mm Fixed Panoramic Lens
- Up to 2048 x 1536 resolution, real-time streaming
- True WDR, up to 120dB
- DC12V / PoE(802.3af)
- Line crossing and intrusiondetection
- BLC/ROI
- IR range Up to 15m (50ft)
- Built-in microphone & speaker
- Audio/Alarm IO/ RS485(-S model)
- IP66 (-V model)
- IK10 vandal proof (-V model)
- Built-in MicroSD card slot
Downloads
Datasheet
Hikvision-DS-2CD6W32FWD-IVS-ss-A1.pdf
Additional Information
|
Additional Features:
|
Mobile App Support (IOS, Android)
|
|
Analytics:
|
Line Crossing
|
|
Audio Support:
|
Built-in Speaker
Built-in Microphone
|
|
Camera Style:
|
Corner
|
|
Color:
|
White
|
|
Compatible Integration (API):
|
ONVIF
|
|
Compression:
|
MJPEG
H.264
H.264 Plus
|
|
Durability:
|
Vandal Proof
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
135
|
|
Lens Size:
|
2mm
|
|
Lens Type:
|
Fixed Lens
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Max. FPS and Resolution:
|
30fps at 1080P
|
|
Night Vision Range (ft):
|
49
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Power Supply:
|
PoE (IEEE 802.3af)
12 VDC
|
|
Protection Code:
|
IP66
IK10
|
|
Resolution:
|
3MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/3"
|
|
Sensor Type:
|
CMOS
|
|
Serial Interface:
|
1x RS485
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
5-year Manufacturer Warranty
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
