Hikvision DS-2CE57H0T-VPITF 3.6MM 5MP IR Outdoor Dome HD CCTV Security Camera

Brand: Hikvision

Part Number: DS-2CE57H0T-VPITF 3.6MM

Write a Review

$77.00

Technical Support

Key Features:

Lens Type : Fixed Lens
Lens Size : 3.6mm Lens
Environmental : Outdoor

Description
Specifications
Compatible products
Additional Information

Description

Hikvision DS-2CE57H0T-VPITF 3.6MM 5MP IR Outdoor Dome HD CCTV Security Camera

The Hikvision DS-2CE57H0T-VPITF 5 MP Outdoor Dome Camera provides high definition analog out- put with a resolution of up to 2560 x 1944 pixels. TurboHD means that the analog signal can be sent over existing coaxial cable, eliminating the need to run new cables for high definition video. EXIR 2.0 is Hikvision’s proprietary IR extended range technology, which has a range of 66 feet (20 meters).

The 2.8 mm, 3.6 mm, and 6 mm fixed lens options are optimized for viewing angles that fit any situa- tion. DWDR (Digital Wide Dynamic Range) ensures that ideal images are captured regardless of the lighting conditions. The camera also supports TVI, AHD, CVI, and CVBS video signals, and is water, dust and impact-resistant (IP67 and IK10 rated).

Key Features:

5 MP, 2560 × 1944 resolution
3.6 mm fixed focal lens, FOV: 80°, vertical FOV: 63°, diagonal FOV: 105°
Smart IR, up to 20 m IR distance
4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
Weatherproof IP67,
Vandal proof IK10
Digital WDR

View AllClose

Specifications

Camera
Image Sensor:	5MP CMOS Image Sensor
Signal System:	PAL/NTSC
Effective Pixels:	2560 (H) × 1944 (V)
Min. Illumination:	0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter Time:	PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s
Lens:	2.8 mm, 3.6 mm, 6 mm fixed lens
Lens Mount:	M12
Adjustment Range:	Pan: 0° to 355°; Tilt:0° to 75°; Rotate: 0° to 355°
Day& Night:	IR cut filter
Video Frame Rate:	TVI: 5M@20fps, 4M@30fps, 4M@25fps, 1080p@30fps, 1080p@25fps; AHD: 5M@25fps, 4M@30fps, 4M@25fps; CVI: 4M@30fps, 4M@25fps; CVBS: PAL/NTSC

Lens
Horizontal Field of View:	2.8 mm, horizontal FOV: 85°, vertical FOV: 63°, diagonal FOV:110° 3.6 mm, horizontal FOV: 80°, vertical FOV: 63°, diagonal FOV:105° 6 mm, horizontal FOV: 57°, vertical FOV: 43°, diagonal FOV:72°

Menu
Image Mode:	STD/HIGH-SAT
Noise Reduction:	2D DNR
Automatic Exposure:	Global/BLC/HLC/DWDR
D/N Mode:	Auto/Color/BW (Black and White)
White Balance:	Auto / Manual
AGC:	Support
Digital WDR:	Yes
Language:	English
Function:	Brightness, Sharpness, Mirror, Smart IR

Interface
Video Out:	Switchable TVI/AHD/CVI/CVBS

General
Material:	Metal
Operating Conditions:	-40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing)
Power Supply:	12 VDC ±25% *You are recommended to use one power adapter to supply the power for one camera.
Power Consumption:	Max. 4.3 W
Impact Protection:	IK10.
Weather Proof:	IP67
IR Range:	Up to 20m
Communication :	HIKVISION-C
Dimension:	Φ 100.4 mm × 82.4 mm (Φ 4" × 3.2")
Weight:	Approx. 362 g (0.80 lb.)

View AllClose

Compatible products

Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
