Description
Hikvision DS-2DE3404W-DE 4MP Outdoor Mini PTZ IP Security Camera with 4x Optical Zoom
This Micro-designed 3" PTZ Mini Dome Camera shows the easiest installation, adjustment and maintenance that you have ever seen. It is a fantastic and practical camera for outdoor. In addition, DS-2DE3404W-DE(T5) support 4 × optical zoom technology, PoE & 12 VDC power supply. Embedded with 1/2.8" progressive scan CMOS chip makes 120 dB WDR and 4 MP real-time resolution possible. With the pan/tilt and 4 × optical zoom Day/Night lens, the camera offers more details in the outdoor environments. Hikvision DS-2DE3404W-DE(T5) Mini PTZ Dome Cameras also features a wide range of functions, including intrusion detection, line crossing detection, motion detection and audio exception, benefitting users with great improvement on security efficiency, more importantly, with key events/objects being recorded for further forensic needs.
Key Features:
- High quality imaging with 4 MP resolution
- Clear imaging against strong back lighting due to 120 dB WDR technology
- Pan and tilt ability enables camera to monitor zones of interest
- 4 × optical zoom allows for closer viewing of subjects in expansive areas
- Water and dust resistant (IP66) and vandal resistant (IK10)
Downloads
Additional Information
|
Alarm Input:
|
1 Channel
|
|
Alarm Output:
|
1 Channel
|
|
Analytics:
|
Motion Detection
Line Crossing
|
|
Aperture:
|
F1.5
|
|
Audio Compression:
|
G.711ulaw
G.711alaw
G.722.1
G.726
MP2L2
PCM
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Camera Style:
|
Mini PTZ
|
|
Certifications:
|
UL Listed
CB
LVD
BIS
LOA
RoHS
WEEE
REACH
RCM
IC
KC
|
|
Compatible Integration (API):
|
ISUP
ISAPI
Hikvision SDK
ONVIF
|
|
Compression:
|
H.265
H.264
MJPEG
H.265 Plus
H.264 Plus
|
|
Connection Type:
|
Wired
|
|
Digital Zoom:
|
16
|
|
Durability:
|
Weatherproof
Vandal Proof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
93.8
31.7
|
|
Focus:
|
Auto Focus
|
|
Languages:
|
English
Turkish
|
|
Lens Size:
|
2.8~12mm
|
|
Lens Type:
|
Motorized (Automatic Zoom) Lens
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Max Power Consumption:
|
10 Watts
|
|
Max. Storage Capacity:
|
256 GB
|
|
Noise Reduction:
|
3D DNR
|
|
Optical Zoom:
|
4x Optical Zoom
|
|
Power Supply:
|
12 VDC
PoE (IEEE 802.3af)
|
|
Product Series:
|
Hikvision Value Series
|
|
Protection Code:
|
IK10
IP66
|
|
Remote Users:
|
Up to 32
|
|
Reset Button:
|
|
|
Resolution:
|
4MP
|
|
S/N Ratio:
|
>52 dB
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.8"
|
|
Sensor Type:
|
CMOS
|
|
Serial Interface:
|
1x RS485
|
|
Shutter Speed:
|
1-1/30000s
|
|
Surge Protection:
|
TVS 4000V
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Web Browser:
|
Firefox 52.0 or above
Safari 11 or above
Chrome 57.0 or above
Internet Explorer 11
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
