Description
Hikvision DS-2DE7232IW-AE 2MP H.265 IR Outdoor PTZ Dome IP Security Camera
Hikvision DS-2DE7232IW-AE 2MP 32x Network IR Speed Dome adopts 1/2.8" progressive scan CMOS chip. With the 32x optical zoom lens, the camera offers more details over expansive areas. This series of cameras can be widely used for wide ranges of high-definition, such as the rivers, roads, railways, airports, squares, parks, scenic spots, and venues, etc.
Key Features Of:
- 1/2.8" progressive scan CMOS
- Up to 1920 × 1080@60fps resolution
- Min. illumination: Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001 Lux @(F1.6, AGC ON) 0 Lux with IR
- 32x optical zoom, 16× digital zoom
- WDR, HLC, BLC, 3D DNR, Defog, EIS, Regional Exposure, Regional Focus
- Up to 150 m IR distance
- 24 VAC & Hi-PoE
- Support H.265+/H.265 video compression
Replacement of:
DS-2DE7230IW-AE
Downloads
Datasheet
DS-2DE7232IW-AE-A1.pdf
User Manual
DS-2DE7232IW-AE-User-Manual-A1.pdf
Quick Start Guide
DS-2DE7232IW-AE-Quick-Start-Guide-A1.pdf
Popular Search
Additional Information
|
Analytics:
|
Motion Detection
|
|
Audio Compression:
|
G.711
G.711u
|
|
Camera Style:
|
Dome
PTZ
|
|
Color:
|
White
|
|
Compatible Integration (API):
|
ONVIF
|
|
Compression:
|
H.264
H.264 Plus
H.265
H.265 Plus
|
|
Durability:
|
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
2
55
|
|
Lens Size:
|
4.8~153mm
|
|
Lens Type:
|
Motorized (Automatic Zoom) Lens
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Max. FPS and Resolution:
|
30fps at 1920 x 1080
|
|
Night Vision Range (ft):
|
492
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Optical Zoom:
|
32x Optical Zoom
|
|
Protection Code:
|
IP66
|
|
Resolution:
|
2MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.8"
|
|
Sensor Type:
|
CMOS
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
