Description
Hikvision DS-9008HWI-ST 8-Channel Embedded Hybrid DVR Digital Video Recorder
DS-9000HWI-ST series HDVR (Hybrid Digital Video Recorder) is a new generation recorder developed by Hikvision independently which can both connect analog and network cameras and provide powerful monitoring functionality. Combined with multiple advanced technologies, such as audio and video encoding & decoding technology, embedded system technology, storage technology, network technology and intelligent technology. It can both work alone as a recorder and cooperate with other devices to build a comprehensive surveillance system. Thanks to these features, the DS-9000HWI-ST series HDVR is widely applied to the surveillance projects of finance, public security, military, education, communication, transportation, etc.
Key features of Hikvision DS-9008HWI-ST
- 8 Channel Analog video input
- Up to 16 Channel IP video input
- No HDD included
- H.264 video compression
- WD1(960*576) resolution real-time recording
- Third-party network cameras supported
- Up to 5 Megapixels playback resolution
- HDMI and VGA output at up to 1920x1080P resolution
- 8/16-ch synchronous playback
- HDD quota and group management
- Dual Gigabit network interfaces
- 1x e-SATA
- 8 SATA interfaces for 8 HDDs
- Up to 6 TB capacity for each disk
- 2U chassis
Downloads
Datasheet
Hikvision-DS-9008HWI-ST-ss-A1.pdf
Quick Start Guide
Hikvision-DS-9008HWI-ST-qsd.pdf
User Manual
Hikvision-DS-9008HWI-ST-um.pdf
Firmware
Hikvision-DS-9008HWI-ST-Firmware-A1
Popular Search
Additional Information
|
Channel Capacity:
|
8 Channels
|
|
Compression:
|
H.264
|
|
Hard Drive Ports:
|
8 SATA Ports
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Max. Incoming Bandwidth:
|
50Mbps
|
|
Max. Recording Resolution:
|
2MP
|
|
Max. Storage Capacity:
|
48 TB
|
|
Outgoing Bandwidth:
|
240 Mbps
|
|
Pre-Installed Storage:
|
No HDD included
|
|
Rack Unit (U):
|
2U
|
|
Recorder Technology:
|
Digital Video Recorder (DVR)
|
|
Video Output:
|
1x VGA
1x HDMI
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
e-SATA:
|
e-SATA
|
