Hikvision DS-9664NI-M16/R M Series 8K 64-Channel NVR, 400 Mbps, No Hard Drive Included

Hikvision DS-9664NI-M16/R M Series 8K 64-Channel NVR, 400 Mbps, No Hard Drive Included

Record from and manage up to 64 cameras with the M Series DS-9664NI-M16/R 64-Channel 8K NVR (No HDD) from Hikvision. This NVR supports IP cameras up to 32MP. It is equipped with sixteen SATA ports that each support an HDD up to 14TB, for a maximum capacity of 224TB (HDDs available separately). H.265+, H.265, H.264+, and H.264 video compressions keep file sizes manageable while maintaining the best quality possible.

Key Features:

• Redundant power supply
• Up to 64-Ch IP camera inputs
• Up to 400Mbps incoming bandwidth and 400Mbps outgoing bandwidth
• Advanced streaming technology enables smooth live view in poor network conditions
• 2 HDMI (different source) and 2 VGA (different source) interfaces, 8K or dual 4K video outputs
• Supports RAID 0, 1, 5, 6, 10 and N+M hot spare for even more reliable data storage, effectively avoids data loss risks
• Supports special cameras, including people counting camera, ANPR (automatic number plate recognition) camera, and fisheye camera
• This NVR supports up to 2-ch at 32MP, 2-ch at 24MP, 4-ch at 12MP, 8-ch at 8MP, 16-ch at 4MP, 32-ch at 1080p decoding capacity

Professional and Reliability

• H.265+ compression effectively reduces the storage space by up to 75%
• Dual-stream recording saves bandwidth
• Adopt stream over TLS encryption technology which provides more secure stream transmission service
• Support double verification for playback and downloading

HD Video Output

• Provide independent HDMI and VGA outputs
• HDMI video output at up to 8K or dual 4K resolution

Storage and Playback

• 16 SATA interfaces for HDD connection (up to 14 TB capacity per HDD)
• 1 eSATA interface for HDD connection
• 16-ch synchronous playback

Smart & POS Function

• Support multiple VCA (Video Content Analytics) events
• Configurable special camera smart functions, such as VCA detection (motion, line crossing, intrusion, etc.), heat map, ANPR, and people counting
• POS information overlay on live view and playback, and POS triggered recording and alarm

Network & Ethernet Access

• 2 self-adaptive 10/100/1000 Mbps Ethernet interfaces
• Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
• Smooth streaming technology
• Support web access without plug-in
