Hikvision ECI-D12F2 2MP Night Vision Outdoor Dome IP Security Camera with 2.8mm Fixed Lens
The Hikvision ECI-D12F Outdoor IR Dome Camera provides high definition output. It supports H.265+ video compression technology, which assures savings in bandwidth and storage.
Key Features:
- Up to 1920 x 1080 Resolution
- 2.8mm Fixed Lens
- 1/2.8" (2 MP) Progressive Scan CMOS
- Up to 1920 x 1080 Resolution
- Minimum Illumination: Color: 0.028 Lux @ (f/2.0, AGC on)
- Main Stream: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
- Up to 100 ft (30 m) EXIR 2.0 Range
- H.265+/H.265/H.264+/H.264/MJPEG
- IP67, IK10 Protection
- 2-Axis Positioning: Pan and Tilt
- Durable Metal Housing
- 12 VDC ± 25% (PoE IEEE802.3af),
- Durable metal housing
Related Products:
- SRSM SRSM, SRS* Anticorrosive Wall Mounting Bracket,
- WM110 Wall mount for indoor cameras
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Aperture:
|
F2.0
|
|
Camera Style:
|
Dome
|
|
Compatible Integration (API):
|
ONVIF Profile G
ONVIF Profile S
ISAPI
|
|
Compression:
|
H.265 Plus
|
|
Day/Night:
|
ICR (True Day/Night)
|
|
Durability:
|
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
114
|
|
Lens Mount:
|
M12
|
|
Lens Size:
|
2.8mm
|
|
Lens Type:
|
Fixed Lens
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Material:
|
Metal
|
|
Max Power Consumption:
|
7 Watts
|
|
Max. FPS and Resolution:
|
30fps at 1920 x 1080
|
|
Minimum Illumination (Color):
|
0.028 lux at F2.0 AGC ON
|
|
Night Vision Range (ft):
|
100
|
|
Noise Reduction:
|
3D DNR
|
|
Power Supply:
|
12 VDC
PoE (IEEE 802.3af)
|
|
Product Series:
|
Hikvision Value Express Series
|
|
Protection Code:
|
IP67
IK10
|
|
Protocols:
|
TCP/IP
ICMP
HTTP
HTTPS
|
|
Resolution:
|
2MP
|
|
Sensor Size:
|
1/2.8"
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/3-1/100000s
|
|
Surge Protection:
|
TVS 2000V
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
2-year Manufacturer Warranty
|
|
Wavelength (nm):
|
850
|
|
Wide Dynamic Range (WDR):
|
Digital WDR (D-WDR)
|
