Description
Hikvision ECI-D64Z2 4MP Outdoor EXIR VF Dome IP Security Camera
The Hikvision ECI-D64Z2 Outdoor Varifocal Dome Camera provides high definition network output. It supports H.265+ video compression technology, which assures savings in bandwidth and storage. EXIR 2.0 is Hikvision’s proprietary IR extended range technology, which has a range of 100 feet (30 meters). The 2.8 mm to 12 mm motorized varifocal lens is optimized for viewing angles that fit any situation. This flexible technology allows for the angle of view to be changed at will in order to focus on an area of interest.
Key Features:
- Minimum Illumination: Color: 0.018 Lux @ (f/1.6, AGC on)
- Up to 2560 x 1440 Resolution
- 2.8 mm to 12 mm Motorized Vari-Focal Lens
- H.265+/H.265/H.264+/H.264/MJPEG
- Main Stream: 20 fps (2560 x 1440), 30 fps (2304 x 1296, 1920 x 1080, 1280 x 720)
- EXIR 2.0 with up to 100ft (30 m) IR Range. 120dB True WDR produces clearer image.
- 12VDC ± 25% (PoE IEEE802.3 af), maximum 10 W. Durable metal housing.
Compatible Products:
- PC135 Pendant Cap for Dome Camera,
- WML Wall mount with junction box - Long,
- CB135 Wire Intake Box for Dome Camera
Downloads
Datasheet
Hikvision-ECI-D64Z2-Datasheet-A1
Quick Start Guide
Hikvision-ECI-D64Z2-Quick-Start-Guide-A1
Firmware
Hikvision-ECI-D64Z2-Firmware-A1
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Aperture:
|
F1.6
|
|
Camera Style:
|
Dome
|
|
Compatible Integration (API):
|
ONVIF Profile S
ONVIF Profile G
ISAPI
|
|
Compression:
|
H.265 Plus
H.264 Plus
H.265
H.264
MJPEG
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
ICR (True Day/Night)
|
|
Durability:
|
Weatherproof
Vandal Proof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
98
28
|
|
Focus:
|
Auto Focus
|
|
Languages:
|
English
|
|
Lens Size:
|
2.8~12mm
|
|
Lens Type:
|
Motorized (Automatic Zoom) Lens
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Max. Storage Capacity:
|
128 GB
|
|
Night Vision Range (ft):
|
100
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Noise Reduction:
|
3D DNR
|
|
Power Supply:
|
PoE (IEEE 802.3af)
12 VDC
|
|
Product Series:
|
Hikvision Value Express Series
|
|
Protection Code:
|
IP67
IK10
|
|
Reset Button:
|
|
|
Resolution:
|
4MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/3"
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/3-1/100000s
|
|
Surge Protection:
|
TVS 2000V
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Wavelength (nm):
|
850
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
