Description
Hikvision ECT-B12F3 2MP Outdoor EXIR Bullet HD Analog Security Camera
The Hikvision ECT-B12 Outdoor EXIR Bullet Camera provides high definition analog output. TurboHD means that the analog signal can be sent over existing coaxial cable, eliminating the need to run new cables for high definition video.
Key Features:
- Minimum Illumination: 0.01 Lux @ (1.2, AGC on), 0 Lux with IR
- Up to 1920 x 1080 Resolution
- 2.8 mm, 3.6 mm, and 6 mm Fixed Lens Options
- 1080p @ 25 fps / 1080p @ 30 fps
- EXIR 2.0 up to 65ft (20 m) IR Range
- 12 VDC ± 25%
Related Products:
- DS-1H18 Video Baluns,
- CBXS Conduit Base
Replacement of:
DS-2CE16C5T-IT1-3.6MM
Downloads
Quick Start Guide
Hikvision-ECT-B12F3-Quick-Start-Guide-A1
Datasheet
Hikvision-ECT-B12F3-Datasheet-A1
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Camera Style:
|
Bullet
|
|
Day/Night:
|
ICR (True Day/Night)
|
|
Dimensions:
|
165 x 62 x 58 mm (6.50 x 2.44 x 2.28 in)
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
92
|
|
Lens Mount:
|
M12
|
|
Lens Size:
|
3.6mm
|
|
Lens Type:
|
Fixed Lens
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Material:
|
Metal
|
|
Max Power Consumption:
|
4 Watts
|
|
Max. FPS and Resolution:
|
25fps at 1080P
|
|
Minimum Illumination (Color):
|
0.01 Lux at F1.2 AGC ON
|
|
Night Vision Range (ft):
|
65
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Power Supply:
|
12 VDC
|
|
Product Series:
|
Hikvision Value Express Series
|
|
Protection Code:
|
IP66
|
|
Resolution:
|
2MP
|
|
S/N Ratio:
|
>62 dB
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/25-1/50000s
|
|
Technology:
|
HD CCTV
|
|
Warranty:
|
2-year Manufacturer Warranty
|
