Description
Hikvision ECT-T12F2 2MP EXIR Outdoor Turret HD Analog Security Camera
The Hikvision ECT-T12 Outdoor EXIR Turret Camera provides high definition analog output. TurboHD means that the analog signal can be sent over existing coaxial cable, eliminating the need to run new cables for high definition video.
Key Features:
- 2MP
- Minimum Illumination: 0.01 Lux @ (1.2, AGC on), 0 Lux with IR
- Up to 1920 x 1080 Resolution
- 2.8 mm fixed lens
- 1080p @ 30 fps
- Smart IR
- IR range up to 65ft (20 m)
- 12 VDC ± 25%
- Weatherproof IP66
Related Products:
- PM Pole mount adapter,
- CM Corner mount adapter,
- CBXS Conduit Base
Replacement of:
DS-2CE56C2N-IT3 2.8MM
DS-2CE56C2T-IRM-2.8MM
Downloads
Datasheet
Hikvision-ECT-T12F2-Datasheet-A1
Quick Start Guide
Hikvision-ECT-T12F2-Quick-Start-Guide-A1
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Camera Style:
|
Turret
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
ICR (True Day/Night)
|
|
Durability:
|
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
103
|
|
Image Enhancements:
|
Auto Gain Control (AGC)
Backlight Compensation (BLC)
|
|
Lens Size:
|
2.8mm
|
|
Lens Type:
|
Fixed Lens
|
|
Manufacturer Website:
|
https://us.hikvision.com/en
|
|
Minimum Illumination (B/W):
|
0 lux with IR illumination on
|
|
Minimum Illumination (Color):
|
0.01 Lux at F1.2 AGC ON
|
|
Night Vision Range (ft):
|
65
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Power Supply:
|
12 VDC
|
|
Product Series:
|
Hikvision Value Express Series
|
|
Protection Code:
|
IP66
|
|
Resolution:
|
2MP
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/25-1/50000s
|
|
Technology:
|
HD CCTV
|
|
Warranty:
|
2-year Manufacturer Warranty
|
|
Wide Dynamic Range (WDR):
|
Digital WDR (D-WDR)
|
