Honeywell L5210 Home LYNX Touch 5210 All-in-one Home/Business Control System

Write a Review
SKU:
L5210
UPC:
886618221750
Maximum Purchase:
100 units
$197.66
Frequently bought together:

Description

Honeywell L5210 Home LYNX Touch 5210 All-in-one Home/Business Control System

Honeywell Home LYNX Touch 5210 all-in-one home and business control system features a crystal clear, full-color 4.3" touchscreen with graphic icons and intuitive prompts for easy operation. It features live video on demand, Z-Wave® automation capabilities, advanced alarm communications, garage door notification and control, tornado alerts for U.S. and Canadian residents, and remote software upgradeability.

The Wi-Fi® module offers the lowest cost alarm communications (including two-way voice) and remote services solution – saving installation time and reducing monthly operating costs.

LYNX Touch 5210 provides security dealers with the flexibility they need to service all of their customers, whether they rely on mobile phones or VoIP.

The Z-Wave connectivity module lets installers integrate security, lighting, locks, thermostats, water valves and more – for local and remote control. With Resideo Total Connect Remote Services, users can control security, thermostats, lighting, locks, receive alerts and more from wherever they are with most smartphones, tablets and computers.

All-in-one home and business control system features a crystal clear, full-color 4.3" touchscreen with graphic icons and intuitive prompts for easy operation.

Key Features:

  • 4.3" color graphic touchscreen
  • On-premises video viewing
  • Wi-Fi support
  • Integrated Z-Wave provides control and integration of:
    - Thermostats
    - Water valves
    - Door locks
    - Sirens
    - Lighting
    - Scenes, schedules and rules
    - Local, automatic and remote control via Resideo Total Connect
  • Advanced Protection Logic™ technology – With APL enabled, the alarm can be reported even if the system is tampered with during the entry and communications delay times. APL can be selected when using Honeywell Home GSM, CDMA and IP communicators.
  • Voice announcement of system and zone status
  • Works with Resideo Total Connect
  • - Remote control of security, garage doors and Z-Wave devices
    - Selected event notifications
  • Voice chime by zone
  • 10 selectable chime tones
  • Automatic stay arming
  • Three panic functions
  • Wall or desk mount
  • Case tamper
  • RF jam detection
  • Hinged cover for easy installation
  • Garage Door Function
  • Integrated Z-Wave® Support
  • Sunrise/sunset lighting control
  • Randomized lighting control
  • IEEE 802.11 B/G/N radio
  • Supports two-way voice
  • GSM radio – protocol supports
    AT&T and Rogers networks
  • ADEMCO® Contact ID Reporting (four or ten digit account numbers)
  • Internet central station communication with L5100-WIFI or ILP5 module
  • GSM cellular central station communication with internal GSM radio
  • CDMA cellular central station communication with internal CDMA radio
  • Resideo Total Connect ready
  • Built-in 85 dB sounder with voice siren
  • UL 985, UL 1023, UL 1635
  • Primary power: plug-in power supply, 110VAC to 9VDC, 2.7A output 300-04705V1 or 300-04065V1
Options:
  • Internal GSM or CDMA radio option
  • Wi-Fi module option
  • ILP5 Internet module option

*CDMA is available in USA only
** Requires 5877GDPK, consisting of the 5877 Relay Receiver and Z-Wave Strobe/Sounder. Not compatible with certain garage doors and garage door openers. Garage door control must have working entrapment protection. See installation instructions for details.

View AllClose

Specifications

  • 4.3" color graphic touchscreen
    - Resolution 470 x 256 pixels
    - 16.7 million colors
    - Intuitive easy-to-use touchscreen interface
    - Words and icons are large, clear and easy to read/understand
    - Menu driven navigation
    - Quick, accurate programming
    - Two dedicated keys – for easy access to the home screen and emergency functions
  • On-premises video viewing
    - Integrated video: System supports one camera, which can be displayed on the touchscreen. Works with compatible Resideo Total Connect Video products only (iPCAM-PT, iPCAM-WO, iPCAM-WI2/B, ACU).
  • Wi-Fi support
    - Alarm communication to AlarmNet® and lifestyle messaging via the user’s Internet connection
    - Two-way voice
  • Integrated Z-Wave provides control and integration of:
    - Thermostats
    - Water valves
    - Door locks
    - Sirens
    - Lighting
    - Scenes, schedules and rules
    - Local, automatic and remote control via Resideo Total Connect
  • Push/Pull content through Resideo   Total Connect
    - Weather available in Fahrenheit or Celsius (one day or five day forecasts)
    - Emergency alerts (tornadoes) – requires Resideo Total Connect with Information Services Package
    - Dealer/central station messages (payments due, sales opportunities, community news)
    - End-user requests for sales or service
  • Advanced Protection Logic technology – With APL enabled, the alarm can be reported even if the system is tampered with during the entry and communications delay times. APL can be selected when using Honeywell Home GSM, CDMA and IP communicators.
  • Voice announcement of system and zone status
  • Family message center (for user recorded messages)
  • Works with Resideo Total Connect
    - Remote control of security, garage doors and Z-Wave devices
    - Selected event notifications
  • Voice chime by zone
  • 10 selectable chime tones
  • Automatic stay arming
  • 32 user codes (Installer, Master, plus 30 Secondary, including Duress and Guest)
  • Three panic functions
  • Wall or desk mount
  • Viewable event log stores up to 128 events
  • Exit error feature (detects difference between an actual alarm and exit alarm caused by leaving a door open after the exit delay expires)
  • Case tamper
  • RF jam detection
  • Quick Exit feature provides users with an exit delay after arming their system
  • Night Stay and Silent Exit modes
  • Hinged cover for easy installation
  • Real-time clock display
  • Garage Door Function
    - Up to three garage doors per system
    - Unique garage door icon
    - View and monitor garage door status
    - Auto-secure feature
    - Remote notification via Resideo   Total Connect
    - Garage door control*
       - Automatically control door via scenes, rules and schedules
       - Locally open/close garage door from touchscreen
       - Remotely open/close garage door via Resideo Total Connect

Zones and Devices

  • One hardwired zone
  • Wireless zones – 64 programmable plus 16 dedicated to keyfobs
  • Supports wireless bidirectional keypads
  • Internal GSM or CDMA radio option
  • Wi-Fi module option
  • ILP5 Internet module option
  • Programmable trigger output

*CDMA is available in USA only
** Requires 5877GDPK, consisting of the 5877 Relay Receiver and Z-Wave Strobe/Sounder. Not compatible with certain garage doors and garage door openers. Garage door control must have working entrapment protection. See installation instructions for details.

Integrated Z-Wave® Support

  • Up to three thermostats (HVAC system or battery powered) with 1°F and 0.5°C set points
  • Four door locks – Jammed locks reported to Resideo Total Connect Remote Services
  • 40 devices (lights, switches and lamp modules)
  • 20 scenes
  • 20 rules (event-based actions)
  • 20 schedules (time-based actions)
  • Sunrise/sunset lighting control
  • Randomized lighting control

Wi-Fi®

  • IEEE 802.11 B/G/N radio
  • Supports alarm reporting
  • Supports two-way voice

Communications

  • GSM radio – protocol supports
    AT&T and Rogers networks
  • ADEMCO® Contact ID Reporting (four or ten digit account numbers)
  • SIA Format Reporting
  • Internet central station communication with L5100-WIFI or ILP5 module
  • GSM cellular central station communication with internal GSM radio
  • CDMA cellular central station communication with internal CDMA radio
  • Selection for primary communication path when using dual paths
  • Touch activated radio registration
  • Radio signal strength display
  • Two-way voice communication over POTS, IP/Wi-Fi, CDMA or GSM
  • Resideo Total Connect ready

Alarm Output

  • Built-in 85 dB sounder with voice siren
  • Steady output for burglary/panic
  • Temporal pulse output for fire and carbon monoxide alarms
  • Long range radio/audio alarm verification

Programming

  • Options stored in EEROM
  • Can be uploaded, downloaded or controlled via IBM-compatible computer using Compass Downloader software and specified modem or via capable GSM, CDMA, Wi-Fi or IP communications module
  • Intuitive programming interface reduces time and mistakes
  • Programming options selected from allowable list
  • Contextual options, defaults and pre-fills for faster set-up

Listings

  • UL 985, UL 1023, UL 1635
  • CAN/ULC-S545, CAN/ULC- Subject-C1023
  • ANSI/SIA CP-01-2010

System Power

  • Primary power: plug-in power supply, 110VAC to 9VDC, 2.7A output 300-04705V1 or 300-04065V1 (300-04063V1 in Canada)
  • Four or 24-hour backup battery: rechargeable nickel-metal hydride battery pack rated at 7.2Vdc
  • Operating temperature:
    32°F – 122°F (0°C – 50°C)

Dimensions (approx)
6.1" H x 8.5" W x 1.71" D
(15.5cm H x 21.6cm W x 4.4cm D)

Part No.Description
L5210LYNX Touch 5210 All-in-One Home and Business Control System
L5210-CNLYNX Touch 5210 All-in-One Home and Business Control System with English/French Languages (Canada)
L5210PKLYNX Touch 5210 with (3) 5816WMWH Door/ Window Transmitters, (1) 5834-4 Four-button Wireless Key and (1) 5800PIR-RES Wireless Motion Detector
L5210PKCNLYNX Touch 5210 with (3) 5816WMWH Door/ Window Transmitters, (1) 5834-4 Four-button Wireless Key and (1) 5800PIR-RES Wireless Motion Detector (Canada)
L5210-24LYNX Touch 5210 with 24-hour Battery
L5100-WIFIWi-Fi IP Communication Module
for L5210 (can be used with internal
GSM radio)
L5100-ZWAVEZ-Wave Control Module for L5210
L5000DMDesk Mount for LYNX Touch
CDMA-L57Internal CDMA Radio
3GLInternal GSM Radio with Two-way Voice Support
3GLCInternal GSM Radio with Two-way Voice Support (Canada)
ILP5Internal Internet Communicator (cannot be used with internal GSM radio)
LT-CABLELYNX Family Power Cord
LYNXRCHKIT-SHA24-hour Backup Battery for L5210 and Internal GSM Radio
LYNXRCHKIT-SCFour-hour Backup Battery for L5210 and Internal GSM Radio
5877GDPKRelay Receiver and Siren/Strobe (includes 5877 Relay Receiver and Z-Wave Strobe/Sounder)
5822TTilt Sensor Transmitter (for garage door status monitoring; works locally and with Resideo Total Connect)
ACUWired/Wireless Analog Converter Unit
IPCAM-WLWired/Wireless Indoor Low-Light IP Camera
IPCAM-PT2AWired/Wireless IP Camera with Pan/Tilt Ability
IPCAM-WOWired/Wireless Color Outdoor IP Camera
