Honeywell WPS47 WIN-PAK SE Integrated Security Software (Standard Edition)
Description
Honeywell WPS47 WIN-PAK SE Integrated Security Software (Standard Edition)
Honeywell’s WIN-PAK 4.7 software solution provides a cost-effective way to integrate and manage access control, video surveillance, and intrusion detection through a single interface. Building upon WIN-PAK’s legendary and robust workstation-based management system, WIN-PAK 4.7 provides an intuitive browser-based interface allowing users to perform common access control actions from virtually anywhere.
WIN-PAK 4.7 can be easily scaled from a single site up to a multi-region, enterprise-level solution without placing restrictions on the number of users or sites being managed. WIN-PAK 4.7 supports third party integrations such as HID's Mobile Access®, BioConnect® Suprema® and Morpho biometrics, point-ofsale systems, visitor management, and HR applications. Using the included WIN-PAK API, your software developers can create custom integrations to meet your integration needs.
- WIN-PAK XE (Express Edition) is the baseline software package for access control only. Manage NetAXS and NS2/NS2P controllers from a single workstation. WIN-PAK XE is ideal for single workstation systems that require access only functionality.
- WIN-PAK SE (Standard Edition) is the software package for access control and standard video integration. The add-on VISTA® intrusion module can further enhance the integration solution. WIN-PAK SE is ideal for small to medium integrated security applications and is available in 1 or 5 workstation versions.
- WIN-PAK PE (Professional Edition) combines all the features of XE and SE plus an unrestricted number of client workstations; VISTA intrusion and advanced video integration; support for multiple department/site applications; multiple communication servers for large applications. All inclusive—no additional upgrades needed.
Key Features:
- System Workstation/Users: 5
- Intrusion Integration: VISTA-128/250 FBPT and BPT
- Integrated Video: 40 NVRs x 64 Cameras - 2,560 Cameras
- Accounts: 1
- Hon-Fin4000 Support: 32
- Eliminates disparate systems and interfaces
- Integrated access, video, intrusion, and fire* systems through one interface
- Direct management of biometrics using HON-FIN4000 controller/reader.
- Provision mobile credentials through WIN-PAK via integration with HID's Mobile Access® platform
- Increases situational awareness, eliminates costly false alarms
- Disarm intrusion system through any valid card swipe at an access control reader
- Arm intrusion system through a valid triple-swipe at an access control reader
- Coordinate intrusion, access, or fire* events with video actions to maximize awareness
- Scales as your business grows
- Unrestricted number of cardholders and system users
- Unrestricted number of sites and access points
- Accommodates up to 40 recorders and 2,560 cameras.
- Minimizes onboarding and training costs
- Intuitive web interface for access management, with embedded Help tool
- Minimizes server deployment costs
- Supports VMWare 6.5 to help leverage existing IT infrastructure and server assets
- Minimizes maintenance and system supervisory costs
- Customizable and automated system reporting functions with email delivery
- Perform common daily access control tasks from anywhere through the web interface
- Included API for custom integrations to third-party systems
IMPORTANT
NOTE
All E-license have a standard lead time of 24-72 business hours. The E-license are sent off to the manufacturer for processing and once they are generated we will receive an email with them. If the 72 business hours have passed and you have not received the e-license please call the customer service department at 214-948-1300 x 411 for assistance.
Specifications
WIN-PAK 4.7 supports the following 64-bit OS:
- Windows Server 2016,
- Windows Server 2012 R2,
- Windows Server 2012,
- Windows 10 Professional.
SQL supported:
- SQL 2016 Standard, Express,
- SQL 2014 Enterprise, Standard, Express
VMWare Supported:
- ESXi 6.5.
Supported Access:
- NETAXS®-123, PRO3200, NETAXS®-4, PW6000 (panel to approved installers (WPP47 only), HON-FIN4000 (not supported by XE)
Supported Video (Not supported by XE):
- FUSION®, MAXPRO NVR, MAXPRO® HYBRID, Performance Series (ENVR-includes 4K)
Supported Intrusion (Not supported by XE):
- VISTA-128BPT, VISTA-250BPT, VISTA-128FBPT, VISTA-250FBPT
Part No. | Description |
---|---|
WIN-PAK 4.7 | |
WPX47 | WIN-PAK XE 4.7 |
WPS47 | WIN-PAK SE 4.7 |
WPP47 | WIN-PAK PE 4.7 |
WIN-PAK XE 4.7 UPGRADES | |
UX47S47 | Upgrade from WPX47 to WPS47 |
UX47P47 | Upgrade from WPX47 to WPP47 |
WIN-PAK SE 4.7 UPGRADES | |
US47P47 | Upgrade from WPS47 to WPP47 |
SOFTWARE SUPPORT* | |
SMUWPXE | SMU - WIN-PAK XE |
SMUWPS | SMU - WIN-PAK SE |
SMUWPP | SMU - WIN-PAK PE |
SRVWPPAPI | WIN-PAK API Developer Support |
*Requires VISTA-128FBPT or VISTA-250FBPT Commercial Fire and Intrusion Panel
*SMU = Software Maintenance Upgrade program provides latest releases per 1-year increments.
