Description
Ikegami ICD-E11-EF 2MP IR 4-in-1 Elevator Corner CCTV Analog Security Camera
High Resolution, Vandal Resistant Camera, IP67, Day/Night, 2.1mm Fixed Lens, Corner Mount This is a high quality AHD (Analog High Definition) Color Camera using the latest CMOS technology, which can produce a high definition image with little distortion. Analog High Definition is a high video definition standard, through the coaxial cable, using the analog modulation technology to transfer progressive-scan HD Video Signal. AHD system is the same as traditional analog system, using common 75-3 coaxial cable to carry out as far as 500 meters HD video without any video signal loss.
Key features of Ikegami ICD-E11-EF
- 2MP
- 2.1mm Fixed Lens
- 1/2.7" CMOS
- NTSC
- Supports AHD, HD-TVI, HD-CVI, 960H
- IR range up to 32ft
- Weatherproof IP67
- Dimensions: 124.72 x 108.58 x 62.55 mm
Downloads
User Manual
ikegami-ICD-E11-EF_manual-A1.pdf
Datasheet
ikeagmi-ICD-E11-EF_CATALOG_US_01-A1.pdf
Popular Search
Additional Information
|
Camera Style:
|
Corner
|
|
Durability:
|
Weatherproof
|
|
Environmental:
|
Indoor
|
|
Lens Size:
|
2.1mm
|
|
Lens Type:
|
Fixed Lens
|
|
Night Vision Range (ft):
|
32
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Protection Code:
|
IP67
|
|
Resolution:
|
2MP
|
|
Sensor Size:
|
1/2.7"
|
|
Sensor Type:
|
CMOS
|
|
Technology:
|
HD CCTV
|
