- 8 Megapixel (4K) InfraRed for Night Vision Outdoor Dome HD-TVI Security Camera, Weatherproof, 2.8mm Fixed Lens, CMHD7382-28F
8 Megapixel (4K) InfraRed for Night Vision Outdoor Dome HD-TVI Security Camera, Weatherproof, 2.8mm Fixed Lens, CMHD7382-28F
$111.29
✅ Help me pick a security camera
- Field of View (Horizontal) : 102.2°Field of View
- Lens Type : Fixed Lens
- Lens Size : 2.8mm Lens
- Sensor Type : CMOS
- Protection Code : IK10 IP67
- Material : Metal
- Environmental : Outdoor
Description
LTS CMHD7382-28F 8MP 4K IR Outdoor Dome HD-TVI Security Camera
Key Features:
- 8.29 MP high performance CMOS
- 3840 x 2160 resolution
- 2.8 mm fixed lens
- Horizontal Field of View: 102.2 degree (2.8 mm)
- Matrix IR 2.0, smart IR, up to 98ft(30 m) IR distance
- DWDR, DNR
- 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
- Weatherproof IP67,
- Vandal proof IK10
- OSD Menu via UTC technology with Platinum DVR
Downloads
Datasheet
CMHD7382-28F Datasheet.pdf
Popular Search
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at [email protected] with any design questions.
Additional Information
Alternative SKUs: |
LTCMHD7382-28F
|
Camera Style: |
Dome
|
Durability: |
Weatherproof
Vandal Proof
|
Environmental: |
Outdoor
|
Field of View (Horizontal): |
102.2
|
Key Features: |
Night Vision (IR)
|
Lens Mount: |
M16
|
Lens Size: |
2.8mm
|
Lens Type: |
Fixed Lens
|
Material: |
Metal
|
NDAA Compliance: |
|
Night Vision Range (ft): |
100
|
Power Consumption: |
5.3 Watts
|
Power Supply: |
12 VDC
|
Protection Code: |
IK10
IP67
|
Resolution: |
8MP (4K)
|
Sensor Type: |
CMOS
|
Technology: |
HD-TVI
|
Warranty: |
3-year Manufacturer Warranty
|
Wide Dynamic Range (WDR): |
Digital WDR (D-WDR)
|
