Description
LTS CMHR6452N-28F 5MP IR 4-in-1 Outdoor Bullet HD-TVI Security Camera - LTCMHR6452N-28F
Key features:
- High Definition Bullet 5MP HD-TVI Camera
- 2.8mm Fixed Lens
- 2560x1944@20fps
- 0.01 Lux, Smart IR
- 2 Matrix IR 2.0 LED up to 66ft
- UTC Control to OSD Menu
- 2D DNR, DWDR
- DC 12V
- Weatherproof IP67
- 4-in-1 Video Output
Replacement of:
CMHR6452N-F
Downloads
Datasheet
CMHR6452N-28F Datasheet.pdf
Specifications
| CAMERA | |
| Image Sensor | 5 MP CMOS |
| Signal System | NTSC/PAL |
| Effective Pixels | 2560(H)*1944(V) |
| Min. Illumination | 0.01 Lux, 0 Lux with IR |
| Lens | 2.8mm; FoV: 85.5° |
| Shutter Speed | 1/30 (1/25) to 1/50,000 s |
| Day & Night | ICR |
| Synchronization | Internal |
| Video Frame Rate | 2560 x 1944@20fps |
| HD Video Output | 1 Analog Output |
| Switch Button | TVI/AHD/CVI/CVBS |
| Angle Adjustment | Pan: 0° to 360°; Tilt: 0° to 180°; Rotate: 0° to 360° |
| MENU | |
| AGC | Support |
| D/N Mode | Color/ BW/ SMART |
| White Balance | ATW/ MWB |
| DWDR | Support |
| BLC | Support |
| Function | Brightness, Sharpness, DNR, Mirror, Smart IR |
| GENERAL | |
| Working Temperature | -40 °F ~ 140 °F (-40 °C ~ 60 °C) |
| /Humidity | Humidity 90% or less (non-condensing) |
| Power Supply | DC 12V |
| Power Consumption | Max. 4.3W |
| Weather Proof Ratings | IP67 |
| IR Range | Up to 66ft (20m) |
| Dimensions | 2.28" × 2.40" × 6.42"(58 mm × 61 mm × 163 mm) |
| Weight | 0.77 lbs (350g) |
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Alternative SKUs:
|
CMHR6452N-28F
|
|
Camera Style:
|
Bullet
|
|
Color:
|
White
|
|
Durability:
|
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
85
|
|
HD CCTV Type:
|
HD-TVI
|
|
Lens Size:
|
2.8mm
|
|
Lens Type:
|
Fixed Lens
|
|
Max. FPS and Resolution:
|
20fps at 2560 x 1944
|
|
Night Vision Range (ft):
|
65
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Noise Reduction:
|
2D DNR
|
|
Product Series:
|
LTS Platinum Series
|
|
Protection Code:
|
IP67
|
|
Resolution:
|
5MP (3K)
|
|
Sensor Type:
|
CMOS
|
|
Technology:
|
HD CCTV
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Wide Dynamic Range (WDR):
|
Digital WDR (D-WDR)
|
