4 Megapixel InfraRed for Night Vision Outdoor Turret Network (IP) Security Camera, H.265 Plus Compression, Weatherproof, SD Card Support, 6mm Fixed Lens, CMIP3C42W-6M

Brand: LTS Security
Part Number: CMIP3C42W-6M
Write a Review
Replacement: LTS LTCMIP3C42NW-MDA 4MP Full Color Outdoor Turret IP Security Camera with Built-in Microphone, 4mm Fixed Lens
Check other similar products:
LTS Security Cameras
Outdoor Security Cameras
Turret Security Cameras
LTS IP Security Cameras
4MP Security Cameras
LTS Turret Security Cameras
Discontinued
  • TS CMIP3C42W-6M 4MP H.265 Full Color Outdoor Turret IP Security Camera
  • 4 Megapixel InfraRed for Night Vision Outdoor Turret Network (IP) Security Camera, H.265 Plus Compression, Weatherproof, SD Card Support, 6mm Fixed Lens, CMIP3C42W-6M

? Help me pick a security camera

Technical Support Technical Support
3 Year Warranty 3 Year Warranty
  • Compression : H.264 Plus, H.265 Plus,
  • Field of View (Horizontal) : 54°Field of View
  • Lens Type : Fixed Lens
  • Lens Size : 6mm Lens
  • Max. Storage Capacity : 128 GB Storage Capacity
  • Protection Code : IP67
  • Environmental : Outdoor

Description

LTS CMIP3C42W-6M 4MP H.265 Color247 Outdoor Turret IP Security Camera

Key Features:

  • Max. 2560 x 1440 @24fps
  • 6 mm fixed lens
  • H.265+, H.264+
  • 120dB WDR
  • 0.0014 @ F1.0 (1/30 s, AGC ON), 0.002 @F1.2 (1/30 s, AGC ON), 0 Lux with LED on
  • 12 VDC & PoE (802.3af, class 3)
  • Built-in micro SD/SDHC/SDXC slot, up to 128G
  • Weatherproof IP67
  • BLC/3D DNR/HLC/Defog
  • 24-hour colorful video

Downloads

Popular Search

LTS Security Cameras
Outdoor Security Cameras
Turret Security Cameras
LTS IP Security Cameras
4MP Security Cameras
LTS Turret Security Cameras

Specifications

Specifications

Camera Series Platinum Series
Camera Resolution 4.0MP
Camera Technology IP / Network
Camera Housing Bullet
Featured Product No
Specifications





Camera

Image Sensor

1/1.8" Progressive Scan CMOS

Min. Illumination

0.0014 @ F1.0 (1/30 s, AGC ON), 0.002 @ F1.2 (1/30 s, AGC ON), 0 Lux with LED on

Shutter Speed

1/3 s to 1/100,000 s

Slow Shutter

Yes

Focal length

4 mm

Focus

Fixed

Aperture

F1.0

FOV

6 mm, horizontal FOV: 54°, vertical FOV: 29°, diagonal FOV: 63°

Lens Mount

M16

Auto-Iris

No

DNR

3D DNR

Wide Dynamic Range

120dB

3-Axis Adjustment

Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°

Compression Standard



Video Compression

Main stream: H.265/H.264

Sub stream: H.265/H.264/MJPEG Third stream: H.265/H.264

H.264 Type

Baseline Profile/Main Profile/High Profile

H.264+

Main stream supports

H.265 Type

Main Profile

H.265+

Main stream supports

Video Bit Rate

32 Kbps to 8 Mbps


Max. Resolution

2560 × 1440



Main Stream

50Hz: 25fps (2560 × 1440, 1920 × 1080, 1280 × 720)

60Hz: 24fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)



Sub Stream

50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)

60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)



Third stream

50Hz: 1fps (1280 × 720, 640 × 480, 640 × 360, 352 × 288, 320 × 240)

60Hz: 1fps (1280 × 720, 640 × 480, 640 × 360, 352 × 288, 320 × 240)

Image Enhancement

BLC/3D DNR/HLC/Defog

Image Settings

Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser

ROI (Region of Interest)

No

Network

Network Storage

Support micro SD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR

Alarm Trigger

Motion detection, video tampering detection, network disconnected, IP address conflict, illegal login, HDD full, HDD error

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour

General Function

One-key reset, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

API

ONVIF (PROFILE S, PROFILE G), ISAPI



Simultaneous Live View

Up to 6 channels



User/Host

Up to 32 users

3 levels: Administrator, Operator and User

Web Browser

IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+

Interface



Communication Interface

1 RJ45 10M/100M self-adaptive Ethernet port

On-board Storage

Built-in micro SD/SDHC/SDXC slot, up to 128 GB

Reset Button

Yes

SVC

H.265 encoding and H.264 encoding support

Smart Feature-set

Behavior Analysis

Line crossing detection, intrusion detection

General

Operating Conditions

-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)



Power Supply

12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3)



Power Consumption

12 VDC, 0.5 A, max: 6 W

PoE: (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max: 7.5 W

Visible Light Range

Warm white LEDs (3000K), up to 98ft(30m)

Protection Level

IP67



Material

Camera body: Front cover: plastic, back cover: metal Bottom base: plastic

Dimensions

Camera: ?130 × 103.6 mm (?5.1? × 4.1?)

Weight

Camera: 500 g (1.1 lb.)


View AllClose

Compatible products

Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.

Additional Information

Alternative SKUs:
LTCMIP3C42W-6M
Camera Style:
Turret
Compatible Integration (API):
ONVIF Profile S ONVIF Profile G
Compression:
H.264 Plus H.265 Plus
Durability:
Weatherproof
Environmental:
Outdoor
Field of View (Horizontal):
54
Lens Size:
6mm
Lens Type:
Fixed Lens
Max. Storage Capacity:
128 GB
Night Vision Range (ft):
98
Night Vision Type:
Night Vision (IR)
Noise Reduction:
3D DNR
Protection Code:
IP67
Resolution:
4MP
SD Card Support:
SD Card Supported
Technology:
Network (IP)
Warranty:
3-year Manufacturer Warranty
Wide Dynamic Range (WDR):
True WDR 120dB
