Description
LTS LTCMIP7042W-28MA 4MP Night Vision Outdoor Dome IP Security Camera with Built-in Mic
Key Features:
- High quality imaging with 4 MP resolution
- Efficient H.265+ compression technology
- Clear imaging even with strong back lighting due to 120 dB WDR
- Water and dust resistant (IP67) and vandal resistant (IK10)
- Matrix 2.0: advanced infrared technology with long IR range
- Support up to 256 GB SD card storage
- Built-in microphone for real-time audio security
Downloads
Datasheet
LTS-Security-CMIP7042W-28MA-Datasheet-A1
Quick Start Guide
LTS-Security-CMIP7042W-28MA-Quick-Start-Guide-A1
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Aperture:
|
F2.0
|
|
Audio Support:
|
Built-in Microphone
|
|
Built-in Analytics:
|
Built-in Analytics
|
|
Camera Style:
|
Dome
|
|
Compatible Integration (API):
|
ONVIF
ISAPI
|
|
Compression:
|
H.264
H.265
MJPEG
|
|
Day/Night:
|
Auto
Day (Color)
Night (B/W)
|
|
Dimensions:
|
120 x 92.2. mm (4.72 x 3.63 in)
|
|
Durability:
|
Weatherproof
Vandal Proof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
98
|
|
Iris:
|
Fixed Iris
|
|
Lens Mount:
|
M12
|
|
Lens Size:
|
2.8mm
|
|
Lens Type:
|
Fixed Lens
|
|
Material:
|
Aluminum
|
|
Max Power Consumption:
|
5 Watts
6.5 Watts
|
|
Max. FPS and Resolution:
|
20fps at 2560 x 1440
|
|
Max. Storage Capacity:
|
256 GB
|
|
Minimum Illumination (B/W):
|
0 lux
|
|
Minimum Illumination (Color):
|
0.01 Lux at F2.0 AGC ON
|
|
Mounting:
|
Wall Mount
Corner Mount
Pole Mount
Ceiling Mount
|
|
Network Interface:
|
1x RJ45 100 M self-adaptive Ethernet interface
|
|
Night Vision Range (ft):
|
98
|
|
Night Vision Type:
|
Night Vision (IR)
|
|
Noise Reduction:
|
3D DNR
|
|
Power Supply:
|
PoE (IEEE 802.3af)
12 VDC
|
|
Product Series:
|
LTS Platinum Series
|
|
Protection Code:
|
IP67
IK10
|
|
Remote Users:
|
Up to 32
|
|
Reset Button:
|
|
|
Resolution:
|
4MP
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/3"
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/3-1/100000s
|
|
Storage Humidity:
|
0% to 95% (non-condensing)
|
|
Storage Temperature:
|
-30 °C to 60 °C (-22 °F to 140 °F)
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Wavelength (nm):
|
850
|
|
Wide Dynamic Range (WDR):
|
True WDR 120dB
|
