4 MegaPixel (2K) InfraRed for Night Vision - H.265+ Video Compression Indoor/Outdoor Dome IP Security Camera with 2.8mm Fixed Lens

Brand: LTS Security

Part Number: CMIP7342W-28M

Write a Review

$141.94

Technical Support

3 Year Warranty

Key Features:

Compression : MJPEG, H.264, H.264 Plus, H.265, H.265 Plus,
Field of View (Horizontal) : 103°Field of View
Max. FPS and Resolution : 30fps at 2688 x 1520
Lens Type : Fixed Lens
Lens Size : 2.8mm Lens
Sensor Type : CMOS
Sensor Size : 1/3" Sensor
Protection Code : IP67 IK10
Color : White
Environmental : Outdoor
Weatherproof : Yes
Sensor Size : 1/3"

Description
Specifications
Compatible products
Additional Information

Description

LTS CMIP7342W-28M 4MP IR H.265+ Outdoor Dome IP Security Camera with 2.8mm Fixed Lens

Key features:

4MP High Definition
2560x1440@30fps
2.8mm Fixed Lens
F1.6: horizontal FOV: 103°
1/3" Progressive Scan CMOS
0.018 Lux @ F1.6
Matrix IR 2.0, IR Range up to 100 feet
H.265, H.265+, H.264, H.264+ Ready
True WDR 120dB
Weatherproof IP67
Vandal Proof IK10
MicroSD Slot up to 128GB
DC 12V, PoE
ONVIF
VCA - Line Crossing, Intrusion Detection, Face Detection

Black Option: LTS CMIP7342WB-28M

Downloads

Datasheet lts-CMIP7342W-28M-A1_7ol6-w0.pdf

User Manual LTS-Security-CMIP7342W-28M-User-Manual-A1

Document Quick-Start-Guide

View AllClose

Specifications

Camera Series

Platinum Series

Camera Resolution

4MP

Camera Technology

IP / Network

Camera Housing

Dome

Featured Product

Specifications

Camera
Image Sensor	1/3" Progres s ive S can CMOS
Min. Illumination	0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed	1/3 s to 1/10,000 s
Lens	2.8 mm: horizontal FOV:98°, vertical FOV: 55°, diagonal FOV: 114°
Lens Mount	M12
Day & Night	IR cut filter
DNR	3D DNR
Wide Dynamic Range	120dB
Angle Adjustment	Pan:0° ~ 360°, T ilt: 0° ~ 75°, Rotation: 0° ~ 360°
Compression Standard
Video Compression	Main stream: H.265+/H.265/H.264 Zip+/H.264 Sub stream: H.265+/H.265/H.264 Zip+/H.264/MJPEG Third stream: H.265+/H.265/H.264 Zip+/H.264
H.264 / H.264+ Type	Main / High Profile
H.265 / H.265+ Type	Main Profile / Sub-stream support
Video Bit Rate	32 Kbps ~ 16 Mbps
Dual Stream	Support
Max. Resolution	2560 × 1440
Main Stream	50Hz:25fps (2560×1440,2304×1296,1920×1080) 60Hz: 30fps (2560×1440,2304×1296,1920×1080)
Sub Stream	50Hz: 25fps (640 × 360, 352 × 288)60Hz: 30fps (640 × 360, 352 × 240)
Third Stream	50Hz: 25fps (1280×720, 640×360, 352×288) 60Hz: 30fps (1280×720, 640×360, 352×240)
Others	Support rotate mode. Brightness, contrast, saturation, and sharpness are adjustable via web browser and client software
Behavioral Analysis	Line crossing detection, intrusion detection
Network
Network Storage	Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger	Motion Detection, VideoTampering, Network Disconnected, IP Address Conflicted, Illegal Login, HDD Full, HDD error
Protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
General	One-key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter
Standard	ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI
Interface
Communication Interface	1 RJ45 10M/100M self-adaptive Ethernet port
Reset	Built-in microSD/SDHC/SDXC slot, up to 128 GB
SVC	H.264 and H.265 encoding
General
Working Temperature /Humidity	-22 °F ~+140 °F(-30 °C ~ +60 °C ) Humidity 95% or less (non-condensing)
Power Supply	DC 12V ± 25%,PoE(802.3af)
Power Consumption	Max.6W
IR Range	Up to 100ft(30m)
Weather Proof Ratings	IP67
Impact Protection	IK10
Dimensions	Φ4.4″ × 3.2″ (Φ111 × 82.4 mm)
Weight	1.3lbs (610g)

View AllClose

Compatible products

Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.

Additional Information

Camera Style:	Dome
Color:	White
Compression:	MJPEG H.264 H.264 Plus H.265 H.265 Plus
Environmental:	Outdoor
Field of View (Horizontal):	103
Key Features:	Night Vision (IR) ONVIF Motion Detection Matrix IR
Lens Size:	2.8mm
Lens Type:	Fixed Lens
Max. FPS and Resolution:	30fps at 2688 x 1520
Night Vision Range (ft):	100ft
Noise Reduction:	3D DNR
Product Series:	Platinum
Protection Code:	IP67 IK10
Resolution:	4MP
SD Card Support:
Sensor Size:	1/3"
Sensor Type:	CMOS
Technology:	Network (IP)
Vandal Proof:
Warranty:	3-year Manufacturer Warranty
Weatherproof:
Wide Dynamic Range (WDR):	True WDR 120dB
