Description
LTS CMIP3C6PW-28SDL 6MP Outdoor Multi-sensor IP Security Camera with Active Strobe Light - LTCMIP3C6PW-28SDL
Our technology provides 24/7 vivid colorful images with F1.0 advanced lenses, high performance sensors and friendly lighting. F1.0 super-aperture collects more light to produce brighter images. Advanced sensor technology can vastly improve the utilization of available light.
Key Features:
- High quality imaging with 8 MP resolution
- One image that presents all the scenes covered by the camera
- 24/7 colorful imaging
- Efficient H.265+ compression technology
- Clear imaging against strong back light due to 130 dB WDR technology
- Focus on human and vehicle classification based on deep learning
- Active strobe light and audio alarm to warn intruders off
- Water and dust resistant (IP67)
Downloads
User Manual
LTS-Security-LTCMIP3C6PW-28SDL-User-Manual-A1
Videos
View AllClose
Compatible products
Camera mounts - enclosures are essential to install security cameras. Each surface will require different type of mount and bracket combination. Please check with our sales team if you need help. You can call us at (866) 441-2288 or email us at sales@a1securitycameras.com with any design questions.
Additional Information
|
Alarm Input:
|
1 Channel
|
|
Alarm Output:
|
1 Channel
|
|
Alternative SKUs:
|
CMIP3C8PW-SDL
|
|
Angle of View:
|
180 Degree
|
|
Aperture:
|
F1.0
|
|
Audio Capability:
|
Two-Way Audio
|
|
Audio Compression:
|
G.711
G.722.1
G.726
MP2L2
PCM
MP3
AAC-LC
|
|
Audio Input:
|
1x Channel
|
|
Audio Output:
|
1x Channel
|
|
Audio Support:
|
Built-in Microphone
Built-in Speaker
|
|
Camera Style:
|
Multi-sensor
|
|
Certifications:
|
WEEE
REACH
RoHS
LVD
UL Listed
RCM
CE
|
|
Color:
|
White
|
|
Compatible Integration (API):
|
ONVIF Profile S
ONVIF Profile G
ONVIF Profile T
ISAPI
SDK
ISUP
|
|
Compression:
|
H.265
H.265 Plus
H.264
H.264 Plus
MJPEG
|
|
Connection Type:
|
Wired
|
|
Day/Night:
|
Day (Color)
Auto
Night (B/W)
|
|
Detect (ft):
|
147.63
|
|
Dimensions:
|
140 x 145.6 mm (5.5 x 5.7 in)
|
|
Durability:
|
Weatherproof
|
|
Environmental:
|
Outdoor
|
|
Field of View (Horizontal):
|
180
|
|
Identify (ft):
|
14.76
|
|
Iris:
|
Fixed Iris
|
|
LED Indicator:
|
|
|
Languages:
|
English
Spanish
|
|
Lens Angle Type:
|
Ultra Wide Lens
|
|
Lens Mount:
|
M12
|
|
Lens Size:
|
2.8mm
|
|
Lens Type:
|
Fixed Lens
|
|
Material:
|
Metal
|
|
Max Power Consumption:
|
12.5 Watts
|
|
Max. FPS and Resolution:
|
20fps at 3632 x 1632
|
|
Max. Storage Capacity:
|
256 GB
|
|
Minimum Illumination (B/W):
|
0 lux
|
|
Minimum Illumination (Color):
|
0.0005 Lux at F1.0 AGC ON
|
|
Mounting:
|
Wall Mount
Pole Mount
Corner Mount
|
|
Night Vision Range (ft):
|
98
|
|
Night Vision Type:
|
Night Vision (Color - White Light)
|
|
Noise Reduction:
|
3D DNR
|
|
Observe (ft):
|
57.41
|
|
Power Supply:
|
12 VDC
PoE (IEEE 802.3af)
|
|
Product Series:
|
LTS Platinum Series
|
|
Protection Code:
|
IP67
|
|
Recognize (ft):
|
29.52
|
|
Remote Users:
|
Up to 32
|
|
Reset Button:
|
|
|
Resolution:
|
8MP (4K)
|
|
S/N Ratio:
|
>52 dB
|
|
SD Card Support:
|
SD Card Supported
|
|
Sensor Size:
|
1/2.5"
|
|
Sensor Type:
|
CMOS
|
|
Shutter Speed:
|
1/3-1/100000s
|
|
Special Technologies:
|
LTS Color 24/7
|
|
Specialized Camera Feature:
|
Strobe Light
Audible Warning
|
|
Storage Humidity:
|
0% to 95% (non-condensing)
|
|
Storage Temperature:
|
-30 °C to 60 °C (-22 °F to 140 °F)
|
|
Technology:
|
Network (IP)
|
|
Warranty:
|
3-year Manufacturer Warranty
|
|
Web Browser:
|
Internet Explorer 10 or above
Chrome 57.0 or above
Firefox 52.0 or above
|
|
Wide Dynamic Range (WDR):
|
WDR 130dB
|
