Description
Luminys N5D-4LA2 4MP LumiLuxSmart Dome IP Security Camera with Dual IR and White-Light LEDs
The Luminys N5D-4LA2 combines advanced LumiLuxSmart technology with vandal-resistant dome housing for versatile indoor and outdoor security applications. This professional 4MP dome camera features intelligent dual illumination that automatically switches between IR-only mode, white-light LED mode, and motion-activated dual illumination to optimize surveillance while preventing light pollution.
Built with a 1/1.8" progressive CMOS sensor and 2.8mm lens, this camera delivers exceptional 2688 × 1520 resolution video at 30 fps with outstanding low-light performance down to 0.0008 Lux in color mode. The compact dome design provides 355° pan adjustment and vandal-resistant IK10 protection, making it ideal for high-risk areas.
Advanced AI capabilities include LumiSearch+ for intelligent target tracking, comprehensive LumiAnalytics suite with face detection, people counting, and queue management, plus Video Content Analytics+ for perimeter protection. The built-in speaker enables two-way communication and audio alerts.
Key Features:
- 4MP resolution with large 1/1.8" sensor for superior image quality
- LumiLuxSmart dual illumination with IR and white-light LEDs
- Vandal-resistant dome housing with IK10 impact protection
- Built-in speaker for two-way audio communication
- LumiSearch+ advanced target tracking and identification
- Comprehensive LumiAnalytics AI suite for business intelligence
- Video Content Analytics+ with line crossing and intrusion detection
- Compact 4.96" diameter design for discreet installation
- 355° pan adjustment for flexible positioning
- IP67 weatherproof rating for outdoor use
- LumiPower support for 3000-foot PoE transmission
- NDAA compliant for government applications
Downloads
Additional Information
|
Alarm Input:
|
1 Channel
|
|
Alarm Output:
|
1 Channel
|
|
Aperture:
|
F1.4
|
|
Audio Compression:
|
G.711Mu
G.711a
PCM
|
|
Audio Input:
|
Built-in Microphone/RCA Input
|
|
Camera Style:
|
Dome
|
|
Certifications:
|
FCC
IC
|
|
Compliance:
|
NDAA
|
|
Compression:
|
H.264
H.264 Plus
H.265
H.265 Plus
MJPEG
|
|
Detect (ft):
|
202ft
|
|
Dimensions:
|
4.96in x 3.94in
|
|
Durability:
|
IK10 Vandal Resistant
|
|
Environmental:
|
Outdoor
|
|
Field of View (Diagonal):
|
139°
|
|
Field of View (Horizontal):
|
112°
|
|
Field of View (Vertical):
|
58°
|
|
Identify (ft):
|
20ft
|
|
Lens Size:
|
2.8mm
|
|
Material:
|
Metal
|
|
Max Power Consumption:
|
9.4W
|
|
Max. FPS and Resolution:
|
30fps at 4MP
|
|
Minimum Illumination (B/W):
|
0.0005 Lux
|
|
Minimum Illumination (Color):
|
0.0008 Lux
|
|
Night Vision Range (ft):
|
98ft
|
|
Night Vision Type:
|
LumiLuxSmart IR/White-Light
|
|
Noise Reduction:
|
3D DNR
|
|
Observe (ft):
|
81ft
|
|
Power Supply:
|
12 VDC
PoE
|
|
Protection Code:
|
IP67
|
|
Recognize (ft):
|
40ft
|
|
Resolution:
|
4MP
|
|
S/N Ratio:
|
>50dB
|
|
SD Card Support:
|
512GB
|
|
Sensor Size:
|
1/1.8"
|
|
Sensor Type:
|
CMOS
|
|
Storage Temperature:
|
-40°F to 140°F
|
|
Technology:
|
Network (IP)
|
|
Wide Dynamic Range (WDR):
|
WDR 130dB
|
